HP-GL2 Emulation
579
Appendix
16
îš„If the Printer is Not Equipped with Hard Disk(s)
When Auto Layout is used, print data is stored in layout memory.
The default layout memory is set at 100 KB. Consequently, when print data exceeding
100 KB is received, a printer error occurs.
If this happens, change the Auto Layout memory capacity on the operation panel.
However, the Auto Layout memory capacity max is 5120 KB. So, print data larger than
5120 KB cannot be received.
When using the Auto Layout function, we recommend the printer be equipped with a
hard disk.
8. Examples of Combinations of Each Function
The following are examples showing the print results that can be achieved by
combining various functions.
îš„Document: Auto, Coordinate Origin: 0 Degrees, Scaling Mode: Paper Size,
Scaling: ON
îš„Document: Auto, Coordinate Origin: 0 Degrees, Scaling Mode: Paper Size,
Scaling: OFF
Print Area
Document Size
Paper Size
Print Area
Document Size
Paper Size
To Next Page
