7/98
Wiring Data 6-4 Xerox DocuPrint P8e Service Manual
6.3 Circuit Board Layout
6.3.1 Controller PWB
J1 PARALLEL CONNECTOR
J8
J7
J5
J2
Control
J1 PARALLEL CONNECTOR
J8
J7
J5
J2
Control
