7/98
Xerox DocuPrint P8e Service Manual 5-21 General Procedures and Information
Table 5.4.2 Status Mode Indications
The Test Print Function
The Test Print Function is available in Status Mode when any of the three Ready codes (00, 01, 02) are
displayed. Pressing the Self-Test button (upper right) initiates the printing of a single page and checks all
functions required to produce a printed image. The Test Print is a page covered with vertical lines about
a quarter inch apart.
While the test print is being produced, the display changes as the Status monitor displays the codes for
each function involved in making the test print. If no problems occur during the Test Print operation the
DCU will again display one of the three Ready codes.
5.4.2.2 Diagnostic Mode
Diagnostic Mode enables the individual testing of thirteen different printer functions.
Diagnostic Mode is entered by simultaneously pressing three keys--DOWN, SHIFT, and STOP--at the
time the printer is switched on. If the printer is already connected and in the Status Mode, it is necessary
to switch off the printer, hold down the three keys, and switch on the printer.
When the DCU enters Diagnostic Mode, the readout window displays “00” and all LEDs on the printer's
Control Panel start to blink. The Control Panel LEDs continue to blink as long as the DCU is in
Diagnostic Mode.
Code
Indication Code Indication
00 Ready (legal) 47 Second feed sensor off
01 Ready (letter) 50 Paper Exit
02 Ready (A4) 60 Open fuser error
20 Print start 61 Warm up
21 Print start (manual) 62 Low heat error
23 Print start (second paper)? 64 Cover open sensor
30 Feed sensor 1st on 68 Overheating error
31 Feed sensor 1st off 70 No paper
33 Feed sensor 1st on (second paper) 71 Paper jam (between feeder and feed
sensor)
34 Feed sensor 1st off (second paper) 72 Jam1 (between feed sensor and exit
sensor
40 Second feed sensor on 73 Jam2 (at exit sensor)
43 Second feed sensor on (second paper) 90 Manual mode
95 LSU not ready
