Xerox DocuPrint P8EX Service Manual

7/98
Repair Analysis Procedures (RAP) 7-14 Xerox DocuPrint P8e Service Manual
CHARACTER DEFECTS:
Garbled print, missing, repeating,
or scrambled characters are
problems relating to font data or
character generation. These are
print defects not related to the
electrophotographic process.
1. Defective font download.
2. Loose / defective cables,
cables out of specification (too
long, etc.).
3. Electromagnetic interference.
4. Defective SIMM.
5. Controller PWB.
6. Engine Controller PWB.
1. Customer may have recently changed/modified
host software or drivers. Reconfigure if
necessary.
2. Inspect cable connections for proper installation
and for damage. Parallel cable must be a good
quality and comply with the IEEE 1284 bi-
directional specification.
3. Relocate printer to another location or to another
power outlet.
4. Replace the SIMM (PL 10).
5. Replace the Controller PWB (PL 10).
6. Replace the Engine Controller PWB (PL 10).
SPOTS:
There are spots of
toner on the page
.
1. Paper.
2. Paper path contaminated.
3. Print Cartridge
4. Fuser Assembly.
5. Transfer Roller.
1. Replace paper from a fresh unopened ream.
2. Clean paper path.
3. Replace Print Cartridge (PL 1).
4. Inspect/clean/replace Fuser Assembly as
necessary (PL 8).
5. If spot repeats every 47.1 mm (1.9 in.), replace
the Transfer Roller (PL 7).
UNFUSED IMAGE: part of or all
of the image is unfused.
1. Damp paper.
2. Paper quality.
3. Light image density
4. Fuser Assembly.
5. Engine Controller PWB.
1. Replace paper from a fresh unopened ream.
2. Be sure that the paper is not extremely rough,
heavily textured, or of a high rag content.
3. Check Remote Control Panel print quality
settings.
4. Inspect/clean/replace Fuser Assembly as
necessary (PL 8).
5. Replace the Engine Controller PWB (PL 10).
STREAKS: Extraneous dark
lines/bands in or across the
process direction. These are
Engine Controller defects not
related to the Controller PWB or
Host Data.
1. Print Cartridge.
2. Fuser Assembly.
3. Transfer Roller.
4. Contaminated paper path.
1. Inspect drum surface for scratches or bands. If
defective, replace the Print Cartridge (PL 1).
2. Inspect fuser rollers for scratches or
contamination. If defective, replace the Fuser
Assembly (PL 8).
3. Inspect Transfer Roller. If defective, replace the
Transfer Roller (PL 7).
4. Clean the paper path.
RESIDUAL IMAGES: The image
from a previous print, which was
not removed during the cleaning
process, has been developed on
the current print.
1. Print Cartridge.
2. Fuser Assembly.
3. Erase Lamps.
4. High Voltage Contacts
1. Replace Printer cartage (PL 1).
2. Inspect/clean/replace Fuser Assembly as
necessary (PL 8).
3. Remove the Print Cartridge, attach the DCU and
perform diagnostic test 04. Verify operation of
the Erase Lamps. Replace as necessary.
4. Verify that all high voltage outputs are to
specification (refer to section 5, DCU operation).
Clean all high voltage contacts.
BACKGROUND: Uniform toner
contamination in non image
areas.
1. Print Density.
2. High voltage output.
3. Print Cartridge.
1. Verify print quality setting in the Remote Control
Panel.
2. Verify that all high voltage outputs are to
specification (refer to section 5, DCU operation).
Clean all high voltage contacts.
3. Replace the Print Cartridge (PL 1).
Defect Definitions Possible Causes Solutions
