Xilinx MicroBlaze Reference Guide

MicroBlaze Processor Reference Guide 13
UG984 (v2018.2) June 21, 2018 www.xilinx.com
Chapter 2: MicroBlaze Architecture
*Addr Memory contents at location Addr (data-size aligned)
:= Assignment operator
= Equality comparison
!= Inequality comparison
> Greater than comparison
>= Greater than or equal comparison
< Less than comparison
<= Less than or equal comparison
+ Arithmetic add
* Arithmetic multiply
/ Arithmetic divide
>> x Bit shift right x bits
<< x Bit shift left x bits
and Logic AND
or Logic OR
xor Logic exclusive OR
op1 if cond else op2 Perform op1 if condition cond is true, else perform op2
& Concatenate. For example “0000100 & Imm7” is the concatenation of the fixed field
“0000100” and a 7 bit immediate value.
signed Operation performed on signed integer data type. All arithmetic operations are
performed on signed word operands, unless otherwise specified
unsigned Operation performed on unsigned integer data type
float Operation performed on floating-point data type
clz(r) Count leading zeros
Table 2-5: Instruction Set Nomenclature (Cont’d)
Symbol Description
Table 2-6: MicroBlaze Instruction Set Summary
Type A 0-5 6-10 11-15 16-20 21-31
Semantics
Type B 0-5 6-10 11-15 16-31
ADD Rd,Ra,Rb 000000 Rd Ra Rb 00000000000 Rd := Rb + Ra
RSUB Rd,Ra,Rb 000001 Rd Ra Rb 00000000000 Rd := Rb + Ra + 1
ADDC Rd,Ra,Rb 000010 Rd Ra Rb 00000000000 Rd := Rb + Ra + C
RSUBC Rd,Ra,Rb 000011 Rd Ra Rb 00000000000 Rd := Rb + Ra + C
ADDK Rd,Ra,Rb 000100 Rd Ra Rb 00000000000 Rd := Rb + Ra
RSUBK Rd,Ra,Rb 000101 Rd Ra Rb 00000000000 Rd := Rb + Ra + 1
Send Feedback

Xilinx MicroBlaze Specifications

General

Architecture	32-bit RISC
Cache	Configurable Instruction and Data Cache
Category	Soft Processor Core
Data Width	32-bit
Memory Management Unit (MMU)	Optional
Floating Point Unit (FPU)	Optional
Interrupt Controller	Configurable
Memory Management	Optional MMU
Configurability	Highly Configurable
Pipeline Stages	3-stage
FPGA Integration	Xilinx FPGAs
Bus Interface	PLB
Debug Interface	JTAG
Typical Clock Speed	Varies depending on FPGA and configuration (e.g., 100-400+ MHz)
Implementation	Soft core (synthesized logic)
Maximum Performance	Varies with FPGA and configuration
Debug Support	Integrated Debug Module
