MicroBlaze Processor Reference Guide 6
UG984 (v2018.2) June 21, 2018 www.xilinx.com
Chapter 1
Introduction
The MicroBlaze™ Processor Reference Guide provides information about the 32-bit soft
processor, MicroBlaze, which is included in Vivado. The document is intended as a guide to
the MicroBlaze hardware architecture.
Guide Contents
This guide contains the following chapters:
Chapter 2, MicroBlaze Architecture contains an overview of MicroBlaze features as well
as information on Big-Endian and Little-Endian bit-reversed format, 32-bit general
purpose registers, cache software support, and AXI4-Stream interfaces.
Chapter 3, MicroBlaze Signal Interface Description describes the types of signal
interfaces that can be used to connect MicroBlaze.
Chapter 4, MicroBlaze Application Binary Interface describes the Application Binary
Interface important for developing software in assembly language for the processor.
Chapter 5, MicroBlaze Instruction Set Architecture provides notation, formats, and
instructions for the Instruction Set Architecture (ISA) of MicroBlaze.
Appendix A, Performance and Resource Utilization contains maximum frequencies and
resource utilization numbers for different configurations and devices.
Appendix B, Additional Resources and Legal Notices provides links to documentation
and additional resources.
