Xilinx Vivado MIPI CSI-2 User Manual

MIPI CSI-2 RX Subsystem v4.0 33
PG232 July 02, 2019 www.xilinx.com
Chapter 2: Product Specification
17 Frame
synchronization
error for VC12
R/W1C 0x0 Asserted when an FE is not paired with a Frame
Start (FS) on the same virtual channel.
16 Frame level error
for VC12
R/W1C 0x0 Asserted after an FE when the data payload
received between FS and FE contains errors. The
data payload errors are CRC errors.
15 Frame
synchronization
error for VC11
R/W1C 0x0 Asserted when an FE is not paired with a Frame
Start (FS) on the same virtual channel.
14 Frame level error
for VC11
R/W1C 0x0 Asserted after an FE when the data payload
received between FS and FE contains errors. The
data payload errors are CRC errors.
13 Frame
synchronization
error for VC10
R/W1C 0x0 Asserted when an FE is not paired with a Frame
Start (FS) on the same virtual channel.
12 Frame level error
for VC10
R/W1C 0x0 Asserted after an FE when the data payload
received between FS and FE contains errors. The
data payload errors are CRC errors.
11 Frame
synchronization
error for VC9
R/W1C 0x0 Asserted when an FE is not paired with a Frame
Start (FS) on the same virtual channel.
10 Frame level error
for VC9
R/W1C 0x0 Asserted after an FE when the data payload
received between FS and FE contains errors. The
data payload errors are CRC errors.
9Frame
synchronization
error for VC8
R/W1C 0x0 Asserted when an FE is not paired with a Frame
Start (FS) on the same virtual channel.
8 Frame level error
for VC8
R/W1C 0x0 Asserted after an FE when the data payload
received between FS and FE contains errors. The
data payload errors are CRC errors.
7Frame
synchronization
error for VC7
R/W1C 0x0 Asserted when an FE is not paired with a Frame
Start (FS) on the same virtual channel.
6 Frame level error
for VC7
R/W1C 0x0 Asserted after an FE when the data payload
received between FS and FE contains errors. The
data payload errors are CRC errors.
5Frame
synchronization
error for VC6
R/W1C 0x0 Asserted when an FE is not paired with a Frame
Start (FS) on the same virtual channel.
4 Frame level error
for VC6
R/W1C 0x0 Asserted after an FE when the data payload
received between FS and FE contains errors. The
data payload errors are CRC errors.
Table 2-27: VCX Frame Error (0x34) (Cont’d)
Bits Name Access
Default
Value
Description
