ZCU106 Board User Guide 18
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 2: Board Setup and Configuration
13 J16 SFP0 enable 1-2 37
14 J62
SFP0 TX bandwidth
• 1-2: Full bandwidth
• 2-3: Low bandwidth
2-3 37
15 J63
SFP0 TX bandwidth
• 1-2: Full bandwidth
• 2-3: Low bandwidth
2-3 37
16 J17 SFP1 enable 1-2 38
17 J64
SFP1 TX bandwidth
• 1-2: Full bandwidth
• 2-3: Low bandwidth
2-3 38
18 J65
SFP1 TX bandwidth
• 1-2: Full bandwidth
• 2-3: Low bandwidth
2-3 38
19 J76
MSP430 programming
•1-2: Reset to GPIO
•3-4: Test to GPIO
Open 42
20 J162
PCIe PRSNT select
•1-2: x1
•3-4: x4
•5-6: GND
• Open: card defined
Open 47
21 J108
SD level shifter internal reference
• 1-2: 3.3V reference
•2-3: GND
1-2 53
22 J110
CVBUS select
•1-2: Device or OTG mode
• 2-3: Host mode
1-2 57
23 J109
ID select
• 1-2: Connector ID
• 2-3: VDD33 ID
2-3 57
24 J112
Shield GND select
•1-2: Capacitor
•2-3: GND
1-2 57
25 J7
Device or host select
• 1-2: Host/OTG
•Open: Device
Open 57
Table 2-2: Default Jumper Settings (Cont’d)
Number Ref. Des. Function Default Schematic Page
