Xilinx ZCU106 User Manual

ZCU106 Board User Guide 12
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 2
Board Setup and Configuration
Board Component Location
Figure 2-1 shows the ZCU106 board component locations. Each numbered component
shown in the figure is keyed to Table 2-1. Table 2-1 identifies the components, references
the respective schematic (0381770) page numbers, and links to a detailed functional
description of the components and board features in Chapter 3.
IMPORTANT: Figure 2-1 is for visual reference only and might not reflect the current revision of the
board.
IMPORTANT: There could be multiple revisions of this board. The specific details concerning the
differences between revisions are not captured in this document. This document is not intended to be
a reference design guide and the information herein should not be used as such. Always refer to the
schematic, layout, and XDC files of the specific ZCU106 version of interest for such details.
CAUTION! The ZCU106 board can be damaged by electrostatic discharge (ESD). Follow standard ESD
prevention measures when handling the board.
