Xilinx ZCU106 User Manual

ZCU106 Board User Guide 17
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 2: Board Setup and Configuration
Jumpers
Table 2-2: Default Jumper Settings
Number Ref. Des. Function Default Schematic Page
1J85
POR_OVERRIDE
• 1-2: Enable
•2-3: Disable
2-3 3
2J12
SYSMON I2C address
• Open: SYSMON_VP_R floating
• 1-2: SYSMON_VP_P pulled down
1-2 3
3J13
SYSMON I2C address
• Open: SYSMON_VN_R floating
• 1-2: SYSMON_VP_N pulled down
1-2 3
4J90
SYSMON VREFP
• 1-2:1.25V VREFP connected to FPGA
•2-3: VREFP connected to GND
1-2 3
5J20
Reset sequencer PS_POR_B
• Open: Sequencer does not control PS_POR_B
• 1-2: Sequencer can control PS_POR_B
1-2 12
6J21
Reset sequencer PS_SRST_B
• Open: Sequencer does not control PS_SRST_B
• 1-2: Sequencer can control PS_SRST_B
1-2 12
7J22
Reset sequencer inhibit
• Open: Sequencer normal operation
• 1-2: Sequencer inhibit (resets stay asserted)
Open 12
8J75
VCCINT_VCU power
• Open: VCCINT_VCU not powered
• 1-2, 3-4, 5-6: VCCINT_VCU powered
1-2
3-4
5-6
16
9J14
ARM® debug VTREF
•Open: VTREF floating
• 1-2: VTREF = VCCOPS3 (1.8V)
1-2 22
10 J15
ARM debug VSUPPLY
• Open: VSUPPLY floating
• 1-2: VSUPPLY = VCCOPS3 (1.8V)
Open 22
11 J56
VCCO_PSDDR_504 select
• 1-2: Switched DDR4 VDDQ
• 3-4: Direct DDR4 VDDQ
1-2 24
12 J159
DDR4 reset suspend enable
• 1-2: Suspend disabled (gate bypass)
• 2-3: Suspend enabled
1-2 24
Send Feedback
