ZCU106 Board User Guide 10
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 1: Introduction
Board Specifications
Dimensions
Height: 7.323 inch (18.60 cm)
Length: 9.5 inch (24.13 cm)
Thickness: 0.062 inch ±0.005 inch (0.157 cm ±0.0127 cm)
Note:
A 3D model of this board is not available.
IMPORTANT: The ZCU106 board height exceeds the standard 4.376 inch (11.15 cm) height of a PCI
Express
®
card.
See ZCU106 board documentation for XDC listing, schematics, layout files, board outline
drawings, etc.
Table 1-1: Zynq UltraScale+ MPSoC ZU7EV Features and Resources
Feature Resource Count
HD banks Two banks, total of 48 pins
HP banks Six banks, total of 312 pins
MIO banks Three banks, total of 78 pins
PS-GTR transceivers (6 Gb/s) Four PS-GTR transceivers
GTH transceivers (16.3 Gb/s) 20 GTH transceivers
VCU One
PCIe hard block Gen1/2/3/4 x4 Two
Logic cells 504 K
CLB flip-flops 460.8 K
Distributed RAM 6.2 Mb
Total block RAM 11 Mb
UltraRAM 27 Mb
DSP slices 1728
