Chapter 2: Board Setup and Configuration
Default Jumper and Switch Settings
Figure 2-2 shows the ZCU106 board jumper header and DIP switch locations. Each
numbered component shown in the figure is keyed to Table 2-2 or Table 2-3 (for default
switch settings). Both tables reference the respective schematic (0381770) page numbers.
X-Ref Target - Figure 2-2
Figure 2-2: Board Jumper Header and DIP Switch Locations
28
5
6
7
27
30
10
9
31
3
12
11
2
1
4
14
8
32
13
16
15
17
18
19
21
20
22 23
24
2526
33
29
X19002-022318
