ZCU106 Board User Guide 15
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 2: Board Setup and Configuration
24
SW14-
SW18
User I/O pushbuttons
E-switch TL3301EP100QG placed in
N,S,W,E,C pattern
60
25 SW20 User I/O reset pushbutton switch E-switch TL3301EP100QG 60
26 SW8 Switches system controller DIP 5-pole C&K SDA05H1SBD 43
27 SW3, SW4 System Reset Pushbuttons E-switch TL3301EP100QG 12
28 U122, J98
CAN1 (MIO 24-25) [B],
2X4 male header
TI SN65HVD232,
SULLINS PBC36DAAN
57
29 SW1 Power On/Off Slide Switch C&K 1201M2S3AQE2 66
30 J52 Power On/Off Slide Switch MOLEX 39-30-1060 66
31 SW5 Program_B Pushbutton E-switch TL3301EP100QG 12
32 J5
FPGA Mezzanine Card Interface,
FMC HPC0 Connector J5
Samtec ASP_134486_01 30-33
33 J4
FPGA Mezzanine Card Interface,
FMC HPC1 Connector J4
Samtec ASP_134486_01 34-37
34 P6 EMIO ARM Trace Port MICTOR 2-5767004-2 61
35 – Board Power System Maxim regulators 67-92
36 P3 PCI Express Endpoint Connectivity FCI 10061913-101CLF 48
37 P11 DisplayPort DPAUX (MIO 27-30) MOLEX 0472720001 51-52
38 J84 Monitoring Voltage and Current ASSMANN AWHW16G-0202-T-R 64
39 J92
Programmable Logic JTAG
Programming Options
TYCO 5103308-2 43
40 J6
Programmable Logic JTAG
Programming Options
ASSMANN AWHW20G-0202-T-R 23
41 U108 HDMI Clock Recovery [B] Silicon Labs SI5324C-C-GMR 42
42 J3 Prototype Header SULLINS PBC36DAAN 63
43
J74/J73,
J72/J42
SMA, MGTH interface RX,
TX SMA connectors
ROSENBERGER 32K10K-400L5 45
44 J69, J70 AES3 Audio Samtec HDBNC–J–P–GN–RA–BH2 50
45 J10, J68 SDI Video Samtec HDBNC–J–P–GN–RA–BH2 49
46 SW6 Switches MPSoC PS mode DIP 4-pole C&K SDA04H1SBD 12
47 SW9 Ethernet PHY Reset E-switch TL3301EP100QG 59
48 J79/J80 User SMA MGT Clock ROSENBERGER 32K10K-400L5 45
49 J93 SYSMON 2X6 vertical male pin header SULLINS PBC36DAAN 3
Table 2-1: ZCU106 Board Component Locations (Cont’d)
Callout
Number
Ref. Des. Feature ([B] = bottom of board) Notes
Schematic
Page
