Xilinx ZCU106 User Manual

ZCU106 Board User Guide 19
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 2: Board Setup and Configuration
Switches
26 J113
Device/host or OTG select
•1-2: Device or host
•2-3: OTG
1-2 57
27 J88
ARM trace VTREF
• 1-2: 3.3V
•Open: 0V
Open 60
28 J38
ARM trace power
• 1-2: 3.3V
•Open: 0V
1-2 60
29 J153
Power inhibit
• Open: Rails power on normally
• 1-2: All rails (except UTIL) OFF
1-2 65
Table 2-2: Default Jumper Settings (Cont’d)
Number Ref. Des. Function Default Schematic Page
Table 2-3: Default Switch Settings
Number Ref. Des. Function Default
Schematic
Page
30
SW6
Note:
For this DIP switch, in relation
to the arrow, moving the switch
toward the label ON is a 0. DIP switch
labels 1 through 4 are equivalent to
mode pins 0 through 3.
Switch PS_MODE select
12
(ON = pull down, OFF = pull up)
1: PS_MODE0 On
2: PS_MODE1 On
3: PS_MODE2 On
4: PS_MODE3 On
31
SW8
Note:
For this DIP switch, in relation
to the arrow, moving the switch
toward the label ON is a 0. 1 through
5 are tied to MSP430 U41 GPIO[1:5].
MSP430 GPIO
42
1: SW0 Off
2: SW1 Off
3: SW2 Off
4: SW3 Off
5: SW4 Off
32 SW13 GPIO All Off 59
33 SW1 Main power switch Off 65
Send Feedback
