ZCU106 Board User Guide 116
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
VADJ_FMC Power Rail
The ZCU106 evaluation board implements the ANSI/VITA 57.1 section 5.5.1 IPMI support
functionality. The power control of the V
ADJ_FMC
power rail is managed by the U41 system
controller. This rail powers both the FMC HPC0 (J5) and the FMC HPC1 (J4) V
ADJ
pins, as well
as the XCZU7EV HP banks 28, 67, and 68. The valid values of the V
ADJ_FMC
rail are 1.2V, 1.5V,
and 1.8V.
At power on, the system controller detects if an FMC module is connected to each interface:
• If no cards are attached to the FMC ports, the V
ADJ
voltage is set to 1.8V.
• When one FMC card is attached, its IIC EEPROM is read to find a V
ADJ
voltage
supported by both the ZCU106 board and the FMC module, within the available
choices of 1.8V, 1.5V, 1.2V, and 0.0V.
• When two FMC cards are attached with differing V
ADJ
requirements, V
ADJ_FMC
is set to
the lowest value compatible with the ZCU106 board and the FMC modules, within the
available choices of 1.8V, 1.5V, 1.2V, and 0.0V.
• If no valid information is found in an FMC card IIC EEPROM, the V
ADJ_FMC
rail is set to
0.0V.
The system controller user interface allows the FMC IPMI routine to be overridden and an
explicit value can be set for the V
ADJ_FMC
rail. Override mode is useful for FMC mezzanine
cards that do not contain valid IPMI EPROM data defined by the ANSI/VITA57.1
specification.
TI MSP430 System Controller
[Figure 2-1, callout 19]
The ZCU106 board includes an on-board MSP430 with integrated power advantage
demonstration and system controller firmware. A host PC resident system controller user
interface (SCUI) is provided on the ZCU106 web page. This GUI enables you to query and
control select programmable features such as clocks, FMC functionality, and power system
parameters. The ZCU106 web page also includes a tutorial on the SCUI (XTP433) [Ref 12]
and board setup instructions (XTP435) [Ref 13].
