Chapter 1: Introduction
Board Features
The ZCU106 evaluation board features are listed here. Detailed information for each feature
is provided in Component Descriptions in Chapter 3.
• XCZU7EV-2, FFVC1156 package
•PL V
CCINT
for range in data sheet
• Form factor for PCIe® Gen[1-3]x4 endpoint (PL GTH transceiver), Micro-ATX chassis
footprint
• Configuration from Quad SPI
• Configuration from SD card
• Configuration over JTAG with platform cable USB header
• Configuration over JTAG with ARM 20-pin header
• Configuration over USB-to-JTAG bridge
•Clocks
°
USER_MGT_SI570
°
PL_74.25M, PL_125M, PL_300M
°
USER_SMA_MGT
°
GTR_DP, GTR_USB3, GTR_SATA
°
PS_REF_CLK
• PS DDR4 72-bit SODIMM (includes ECC)
• PL DDR4 64-bit component (4x16-bit)
• PS-GTR assignment
°
DisplayPort (two GTRs)
°
USB3 (one GTR)
°
SATA (one GTR)
• PL GTH transceiver assignment (20 total)
°
High-definition multimedia interface (HDMI®) (three GTH transceivers)
°
FMC HPC1 DP (one GTH transceiver)
°
PCIe (four GTH transceivers)
°
SDI (one GTH transceiver)
°
SMA (one GTH transceiver)
