ZCU106 Board User Guide 23
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 3
Board Component Descriptions
Overview
This chapter provides a detailed functional description of the board’s components and
features. Table 2-1, page 14 identifies the components, references the respective schematic
page numbers, and links to the corresponding detailed functional description in this
chapter. Component locations are shown in Table 2-1, page 14.
Component Descriptions
Zynq UltraScale+ XCZU7EV MPSoC
[Figure 2-1, callout 1]
The ZCU106 board is populated with the Zynq UltraScale+ XCZU7EV-2FFVC1156 MPSoC,
which combines a powerful processing system (PS) and programmable logic (PL) in the
same device. The PS in a Zynq UltraScale+ MPSoC features the ARM
®
flagship Cortex
®
-A53
64-bit quad-core processor and Cortex-R5 dual-core real-time processor.
Production ZCU106 evaluation boards will ship with -2 speed grade devices. Support of
multiple speed grades requires voltage adjustments.
The V
CCINT
supplies are user adjustable via the PMBus with the voltage ranges listed in
Table 3-1 to support multiple Zynq UltraScale+ MPSoC speed grades.
