ZCU106 Board User Guide 128

UG1244 (v1.0) March 28, 2018 www.xilinx.com

Appendix B

Master Constraints File Listing

Overview

The master Xilinx design constraints (XDC) file template for the ZCU106 board provides for

designs targeting the ZCU106 evaluation board. Net names in the constraints listed

correlate with net names on the latest ZCU106 evaluation board schematic. Identify the

appropriate pins and replace the net names with net names in the user RTL. See the Vivado

Design Suite User Guide: Using Constraints (UG903) [Ref 9] for more information.

For detailed I/O standards information required for a particular interface, see the constraint

files generated by tools such as the memory interface generator (MIG) and base system

builder (BSB).

The FMC connectors J5 (HPC0) and J4 (HPC1) are connected to MPSoC banks powered by

the variable voltage V

AJ_FMC

. Because different FMC cards implement different circuitry, the

FMC bank I/O standards must be uniquely defined by each customer.

IMPORTANT: The XDC file can be accessed on the Zynq UltraScale+ ZCU106 Development Kit website.

ZCU106 Board Constraints File Listing

#CLOCKS

#PS_REF_CLK 33.33 MHz U69 SI5341B

#Other net PACKAGE_PIN R24 - PS_REF_CLK Bank 503 - PS_REF_CLK

#CLK_125 125 MHz U69 SI5341B

set_property PACKAGE_PIN G9 [get_ports "CLK_125_N"] ;

set_property IOSTANDARD LVDS [get_ports "CLK_125_N"] ;

set_property PACKAGE_PIN H9 [get_ports "CLK_125_P"] ;

set_property IOSTANDARD LVDS [get_ports "CLK_125_P"] ;

#CLK_74_25 74.25 MHz U69 SI5341B

set_property PACKAGE_PIN D14 [get_ports "CLK_74_25_N"] ;

set_property IOSTANDARD LVDS [get_ports "CLK_74_25_N"] ;

set_property PACKAGE_PIN D15 [get_ports "CLK_74_25_P"] ;

set_property IOSTANDARD LVDS [get_ports "CLK_74_25_P"] ;

Send Feedback
