ZCU106 Board User Guide 69
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
Platform Management Unit GPI (MIO 26)
PS-side MIO 26 is reserved as an input to the platform management unit (PMU) for
indicating a warm boot. PS bank 501 MIO26 (U1.A29) is connected to the I2C0 U61
TCA6416APWR bus expander (port P04 U61.8) through L/S U147 SN74AVC1T45. See the
Zynq UltraScale+ MPSoC Technical Reference Manual (UG1085) [Ref 2] for more details on
the PMU interface.
DisplayPort DPAUX (MIO 27-30)
The Zynq UltraScale+ MPSoC provides a VESA DisplayPort 1.2 source-only controller that
supports up to two lanes of main link data at rates of 1.62 Gb/s, 2.70 Gb/s, or 5.40 Gb/s. The
DisplayPort standard defines an auxiliary channel that uses LVDS signaling at a 1 Mb/s data
rate, which is translated from single-ended MIO signals to the differential DisplayPort AUX
channel, DPAUX (see Table 3-27). The DisplayPort circuit is shown in Figure 3-22.
X-Ref Target - Figure 3-21
Figure 3-21: PS-Side CAN Bus Interface Connector
Table 3-27: DPAUX/MIO Connections
XCZU7EV (U1) Pin Net Name
Level Shifter U114
Pin Name Pin #
A33 MIO30_DP_AUX_IN 2A1 8
A32 MIO29_DP_OE 1A2 7
A31 MIO28_DP_HPD 2A2 9
A30 MIO27_DP_AUX_OUT 1A1 6
60Ω 60Ω
4700 pF
CANH_TERM CANL_TERM
CANL_TERM
CANH_TERM
CANHCANL
GNDGND
X16534-052417
J98
Send Feedback
