Xilinx ZCU106 User Manual

ZCU106 Board User Guide 24
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
Table 3-1: Recommended Operating Conditions
Symbol Description Min Typ Max Units
Processing System
V
CC_PSINTFP
PS full-power domain supply voltage. 0.808 0.850 0.892 V
For -1LI and -2LE (V
CCINT
= 0.72V) devices:
PS full-power domain supply voltage.
0.808 0.850 0.892 V
For -3E devices:
PS full-power domain supply voltage.
0.873 0.900 0.927 V
V
CC_PSINTLP
PS low-power domain supply voltage. 0.808 0.850 0.892 V
For -1LI and -2LE (V
CCINT
= 0.72V) devices:
PS low-power domain supply voltage.
0.808 0.850 0.892 V
For -3E devices:
PS low-power domain supply voltage.
0.873 0.900 0.927 V
Programmable Logic
V
CCINT
PL internal supply voltage. 0.825 0.850 0.876 V
For -1LI and -2LE (V
CCINT
= 0.72V) devices:
PL internal supply voltage.
0.698 0.720 0.742 V
For -3E devices: PL internal supply voltage. 0.873 0.900 0.927 V
