Xilinx ZCU106 User Manual

ZCU106 Board User Guide 14
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 2: Board Setup and Configuration
Table 2-1: ZCU106 Board Component Locations
Callout
Number
Ref. Des. Feature ([B] = bottom of board) Notes
Schematic
Page
1U1
Zynq UltraScale+ XCZU7EV MPSoC,
GTH Transceivers, PS GTR Transceivers
XCZU7EV-2FFVC1156
2J1PS-Side: DDR4 SODIMM Socket
LOTES ADDR0067-P001A/KINGSTON
KVR21SE15S8/4
24
3
U2,
U99-U101
DDR4 Component Memory, (4 Gb) Micron MT40A256M16GE-075E 26-29
4
U119,
U120
Quad SPI Flash Memory (MIO 0–12) [B] Micron MT25QU512ABB8ESF-0SIT 53
5 U116, J96
USB 3.0 Transceiver and USB 2.0 ULPI
PHY (USB 3.0 A connector)
SMSC USB3320-EZK, KYCON
KMMX-AB10-SMT1SB30TR
58
6 J100 SD Card Interface Hirose DMIAA-SF-PET(21) 54
7 U152, J2
Programmable Logic JTAG
Programming Options
FTDI FT232HL-REEL,
Hirose ZX62D-AB-5P8
22
8U69
SI5341B 10 Independent Output
Any-Frequency Clock Generator [B]
Silicon Labs SI5341B-B05071-GM 44
9U42Programmable User Clock [B] Silicon Labs SI570BAB001614DG 45
10 U56
Programmable User MGT Clock,
Cooling Fan Connector
Silicon Labs SI570BAB000544DG 45
11 U20 SFP/SFP+ Clock Recovery [B] Silicon Labs SI5328B-C-GMR 46
12 U98, P12
GEM3 Ethernet (MIO 64-77),
10/100/1000 MHz Tri-Speed Ethernet
PHY
TI DP83867IRPAP,
Halo HFJ11-1G01E-L12RL
59
13 U40, J83 CP2108 USB UART Interface
Silicon Labs CP2108-B02-GM,
Hirose ZX62D-AB-5P8
47
14 U94, P7 HDMI Video Output [B]
TI SN65DP159RGZ, TE Connectivity
1888811-1
40
15 U19, P7 HDMI Video Output
TI TMDS181IRGZT,
TE Connectivity 1888811-1
41
16
U60, U61,
U97
I2C0 (MIO 14-15), I2C0 bus switch and
two expanders [B]
TI PCA9544ARGYR,
Two each TI TCA6416APWR
64
17 U34, U135
I2C1 (MIO 16-17), I2C1 bus switches
[B]
Two each TI TCA9548APWR 65
18 P1, P2 SFP/SFP+ Connectors Molex 74441-0010 38-39
19 U41 TI MSP430 System Controller [B] TI MSP430F5342 43
20 J87 User PMOD GPIO Headers SULLINS PBC36DAAN 62
21 J160, J55
User PMOD GPIO Headers SULLINS PPPC062LJBN-RC 56
22 DS37-DS44 User I/O, Power and Status LEDs GPIO LEDs, GREEN 0603 60
23 SW13 User I/O DIP switch C&K SDA08H1SBD 60
