Xilinx ZCU106 User Manual

ZCU106 Board User Guide 64
UG1244 (v1.0) March 28, 2018 www.xilinx.com
Chapter 3: Board Component Descriptions
Table 3-22: I2C0 U60 Address 0x75 MUX Target Bus Connections
Reference
Designator
Address Device
PS_PMBUS (U60 Port 0)
U76 0x40 INA226 VCCPSINTFP
U77 0x41 INA226 VCCPSINTLP
U78 0x42 INA226 VCCPSAUX
U87 0x43 INA226 VCCPSPLL
U85 0x44 INA226 MGTRAVCC
U86 0x45 INA226 MGTRAVTT
U93 0x46 INA226 VCCO_PSDDR_504
U88 0x47 INA226 VCCOPS
U15 0x4A INA226 VCCOPS3
U92 0x4B INA226 VCCPSDDRPLL
PL_PMBUS (U60 Port 1)
U79 0x40 INA226 VCCINT
U81 0x41 INA226 VCCBRAM
U80 0x42 INA226 VCCAUX
U84 0x43 INA226 VCC1V2
U16 0x44 INA226 VCC3V3
U65 0x45 INA226 VADJ_FMC
U74 0x46 INA226 MGTAVCC
U75 0x47 INA226 MGTAVTT
MAXIM_PMBUS (U60 Port 2)
J84 NA PMBUS CONN. SDA PIN 3/SCL PIN 1
U47 0x13 MAX15301 VCCINT
U7 0x14 MAX15303 VCCBRAM
U6 0x15 MAX15303 VCCAUX
U10 0x16 MAX15303 VCC1V2
U9 0x17 MAX15303 VCC3V3
U63 0x18 MAX15301 VADJ_FMC
U95 0x72 MAX20751 MGTAVCC
U96 0x73 MAX20751 MGTAVCC
U46 0x0A MAX15301 VCCPSINTFP
U4 0x0B MAX15303 VCCPSINTLP
U18 0x1D MAX15303 DDR4_DIMM_VDDQ
U13 0x10 MAX15303 VCCOPS
