Zynq-7000 PCB Design Guide www.xilinx.com 66
UG933 (v1.8) November 7, 2014
Chapter 5: Processing System (PS) Power and Signaling
the Zynq-7000 AP SoC device and SD chip. PCB and package delay skew for SD_DAT[0:3]
and SD_CMD relative to SD_CLK should be less than ±50 ps. Asynchronous signals SD_CDn
and SD_WPn have no timing relationship to SD_CLK.
The Cdn and WPn lines should both be pulled up with their own 50 kΩ resistors to the MIO
I/O voltage.
RECOMMENDED: It is highly recommended to perform a signal integrity analysis on the CLK line at the
near (close to Zynq-7000 AP SoC device) and far ends.
Temperature Sensing Diodes
Note: If unused, the DXP and DXN pins for the temperature sensing interface should be tied
to ground.
Trace Port Interface Unit (TPIU)
When operating the TPIU in MIO mode, the trace clock output should be delayed by
approximately one half clock period. This can be done on the PCB, or by the debugging
device (ARM_DSTREAM, Lauterbach, Agilent, etc).
UART
For MIO pins 14 and 15, keep trace delays below 1.75 nS. Match TX line to +/-50 pS, and RX
line to +/-50 pS.
Trace B
Tx Path: The clock to data skew should be targeted to 2.6 ns to center align the clock to the
data for all voltages. This shift must be provided either on the board or by the trace
debugger tools. ARM DSTREAM, Lauterbach & Agilent Trace debugger tools support
individually adjustable trace clk/data signals.
USB ULPI
PCB and package delay should be kept to 2.0 ns or shorter to meet the 60 MHz operating
target. PCB and package delay skew for DATA[7:0], DIR, NXT, and STP should be less than
±100 ps.
RECOMMENDED: It is recommended that the clock trace should always be shorter than the data and
control signals to improve hold time.
