Xinje DS5F-43P0-PTA - U1-XX; U2-XX

186
U1-XX:
Code
Contents
Unit
U1-00
present alarm code
U1-01
present warning code
U1-02
U phase current when alarming
0.01A
U1-03
V phase current when alarming
0.01A
U1-04
bus voltage when alarming
V
U1-05
IGBT temperature when alarming
℃
U1-06
torque current when alarming
0.01A
U1-07
excitation current when alarming
A
U1-08
position offset when alarming
Instruction
pulse
U1-09
speed when alarming
rpm
U1-10
Seconds(low 16-bit) when alarming, cumulated seconds from the first
time power-on
s
U1-11
Seconds(high 16-bit) when alarming, cumulated seconds from the first
time power-on
s
U1-12
this time running error numbers, counting after power on this time
U1-13
this time operation warning numbers, counting after power on this time
U1-14
historical alarm amounts
U1-15
historical warning amounts
U1-16
Recent 2nd alarm code
U1-17
Recent 3rd alarm code
U1-18
Recent 4th alarm code
U1-19
Recent 5th alarm code
U1-20
Recent 6th alarm code
U1-21
Recent 2nd warning code
U1-22
Recent 3rd warning code
U1-23
Recent 4th warning code
U1-24
Recent 5th warning code
U1-25
Recent 6th warning code
U2-XX:
Code
Contents
Unit
U2-00
Power on times
U2-01
series
U2-02
Model (low 16-bit)
U2-03
Model (high 16-bit)
U2-04
out of factory date: year
U2-05
out of factory date: month
U2-06
out of factory date: day
U2-07
Firmware version
U2-08
Hardware version
U2-09
Total running time (from the first time power on)
hour
U2-10
Total running time (from the first time power on)
minute
U2-11
Total running time (from the first time power on)
second
U2-12
This time running time (from this time power on)
hour
U2-13
This time running time (from this time power on)
minute
U2-14
This time running time (from this time power on)
second
U2-15
Average output power (from the first time enabled, average power in
the process of enabling)
1W
