5.4.4 Speed control (external analog value)
Parameter
Overview
Reference
chapter
P0-01 Control mode selection
Set to 4: external analog value
5.4.4.1
P3-00 Analog voltage
corresponding to rated speed
Set the speed command voltage required to run the
servo motor at rated speed, unit: 0.001V
5.4.4.2
P3-09 Soft start acceleration time
P3-10 Soft start deceleration time
Set the acceleration deceleration time, unit ms
5.4.1.1
P3-02 analog voltage speed filter
Unit 0.01ms
5.4.4.3
P3-03 speed command input dead
time voltage
Unit 0.001V
5.4.4.6
P3-04 analog speed direction
switching
Switch the input direction of analog speed command
5.4.4.4
5.4.4.1 External analog speed mode
Parameter
Setting
value
Meaning
Modify
Effective
P0-01
4
Speed control: external analog value
Servo bb
At once
Function: speed command is given by external analog quantity. The analog voltage command input
from the V-REF terminal is given as the speed control signal to control the speed.
Note:
(1) Direction switching: positive and negative voltage or SPD-D (P5-27) can control direction.
(2) Refer to section 3.2.4 analog input circuit for hardware wiring.
5.4.4.2 Analog value corresponding to rated speed
Parameter
Meaning
Default
setting
Unit
Setting range
Modify
Effective
P3-00
V-REF function
distribution
0
-
0~2
Servo bb
At once
P3-01
Analog quantity
corresponding to rated
speed
10000
0.001V
1500~30000
Servo bb
At once
Function description: set the speed command voltage (V-REF) required to run the servo motor at rated
speed.
For example, P3-01 = 5000, indicating that when the analog input voltage is 5.00V, the motor operates
at the rated speed;
P3-01 = 8000, indicating that when the analog input voltage is 8.00V, the motor operates at the rated
speed.
