Xinje DS5F-43P0-PTA - Speed Control (Pulse Frequency Command); Parameter Meaning; Speed Command Filter Time; Parameter

85
5.4.3 Speed control (pulse frequency command)
Parameter
Overview
Reference
chapter
P0-01 Control mode selection
Set to 7: external pulse speed mode
5.4.3.1
P0-10 Pulse command form
Set pulse form
0-CW/CCW
1-AB
2-P+D
5.3.2.2
P0-15 Command pulse frequency at
rated speed
Determine the linear relationship between the
command pulse frequency and the speed
5.4.3.3
P0-16 Speed command pulse filter
time
When the command pulse frequency is relatively
low, setting this parameter properly can reduce the
speed fluctuation
5.4.3.4
P5-71 Function selection of
direction terminal in pulse speed
mode
change the pulse direction
5.4.3.5
5.4.3.1 External pulse speed mode
Parameter
Setting
value
Meaning
Modify
Effective
P0-01
7
Speed control: pulse frequency speed command
Servo bb
At once
Function: speed command is decided by external pulse frequency, but not related to pulse quantity.
The wiring is the same as position command. Select CW, CCW mode or direction + pulse mode, AB
phase pulse mode.
5.4.3.2 Pulse frequency command
Pulse frequency command is the same as external pulse command position control, refer to chapter
5-3-2.
5.4.3.3 Command pulse frequency at rated speed
Parameter
Meaning
Default
setting
Unit
Range
Modify
Effective
P0-15
command pulse
frequency at rated
speed
1000
100Hz
0～10000
Servo bb
At once
Note: the unit is 100Hz.
Example: P0-15=300, command pulse frequency at rated speed=30kHz;
P0-15=1000, command pulse frequency at rated speed= 100kHz.
5.4.3.4 Speed command pulse filter time
Parame
ter
Meaning
Default
setting
Unit
Range
Modify
Effective
P0-16
speed command pulse
filter time
100
0.01ms
0～10000
Servo bb
At once
When the command pulse frequency is low, setting a suitable value for this parameter can decrease
the speed fluctuation.
5.4.3.5 Speed command pulse direction
Parameter
Meaning
Default
setting
Unit
Range
Modify
Effective
P5-71
Function selection
of direction
terminal in pulse
speed mode
0
-
0～1
Servo bb
At once
