Xinje DS5F-43P0-PTA - Page 83

81
5.4.1.2 Zero clamp (/ZCLAMP)
1. Overview
This function is used when host controller uses speed command input and the servo system isn’t
configured the position loop. In other words, the function will be used when the motor must stop and
enter lock state even the V-REF input voltage is not zero.
When set ON the zero clamp function, it will configure the position loop inside the servo, the motor
will do zero clamp within ±1 pulse at this position. The motor will return to zero clamp position even it
is run by external force.
The present speed must be smaller than zero clamp speed when using zero clamp function, it can clamp
the motor shaft from moving. The motor will switch from speed mode to position mode when starting
the zero clamp function. At this time, rotate the motor shaft, it will return to the original position. It will
not return to original position in speed mode, because it has no position feedback.
2. Input signal setting
Parame
ter
Signal
Setting
Meaning
Range
P5-31
Zero clamp
/ZCLAMP
n.0000
(default)
Defaulted is not distribute to input
terminal
/Z-CLAMP signal is
distributed to input
terminal by parameter
P5-31, Range:
0000-001A.
n.0002
Input signal from SI2 terminal
3. Parameter setting
parameter
Meaning
Default
setting
Unit
Range
Change
Effective
P3-13
Zero clamp speed
10
rpm
0～300
Servo bb
At once
P3-12
Zero clamp mode
0
-
0～3
Servo bb
At once
P3-12 setting
Contents
0
ZCLAMP input signal is ON, forced speed command is 0, when the speed below
P3-13, switch to position mode and the servo lock in this position.
1
ZCLAMP input signal is ON, forced set the speed command to 0.
2
ZCLAMP input signal is ON, the speed below P3-13, switch to position mode and
the servo lock in the position.
Note: after entering zero clamp mode, present setting speed is higher than P3-13,
motor doesn’t run, the ZCLAMP signal must be OFF, then motor will run again.
3
ZCLAMP signal is ON, the setting speed is less than P3-13, switch to position
control mode, and servo is locked at this position. At this time, if setting speed is
over P3-13, the motor will run again.
5.4.1.3 Speed reach signal (/V-RDY)
 Related parameter
Parameter
Signal
Default
setting
Suitable
mode
Meaning
Modify
Effective
P5-51
/V-RDY
n.0000
3, 4, 7
Speed reach signal
Anytime
At once
Parameter
Meaning
Default
setting
Unit
Range
Modify
Effective
P5-05
Reach speed
50
rpm
0～10000
Anytime
At once
Speed arrival signal output condition
When the actual motor speed is greater than P5-05, output speed reach signal (/V-RDY).
