DRIVE SHAFT, FORWARD GEAR AND SHIFT ROD
LOWR
1
2
a
3
a
1
4
5
1
1
5
8
7
6
9
0
a
b
2. Install:
9Upper bushing 6
3. Install:
9Oil seal
NOTE:
Use the oil seal installer (bearing attach-
ment), install the two oil seals at the speci-
fied depth from top of the lower case mat-
ing surface (one by one).
6-21
Bushing installer ass’y 2:
YB-06029
Needle bearing installer 3:
YB-06169
Bushing installer center bolt 4:
90890-06601
Bushing attachment 5:
90890-06651
Bushing installer attachment
77
:
YB-06027/90890-06651
Driver rod
88
:
YB-06229/90890-06652
A
B
A For USA and CANADA
B Except for USA and CANADA
Bearing attachment
99
:
YB-06016/90890-06634
Driver rod
00
:
YB-06071/90890-06606
Oil seal set depth :
aa
:8.0 mm (0.3 in)
bb
:1.0 mm (0.04 in)
