MOTIF XS6/MOTIF XS7/MOTIF XS8

to PNB-PN-CN1

Data dial

DEC/NO

EXIT

INC/YES

ENTER/EXECUTE

VOICE

SEQUENCER SONG

INTEGRATED

SAMPLING

FILE

EDIT / COMPARE

UTILITY

JOB

SEQUENCER MIXING

PERFORM

SEQUENCER PATTERN

MASTER

SEQ SETUP

STORE/SET LOCATE

COMMON EDIT

to Touch volume

to JKAN-JA-CN1

PNC Circuit Board

PNB-RB Circuit Board

Component side

（部品側）

PNB-RB: 2NA-WG45440

PNC: 2NA-WG45450
