Yamaha Motif XS Series User Manual

52
MOTIF XS6/MOTIF XS7/MOTIF XS8
VR3
VH335600
Slide Variable Resistor B 10K RS45111A9
スライドＶＲ
VOLUME 1 03
*
VR4
WG945000
Rotary Variable Resistor B 10.0K RK11K1140D
ロータリーＶＲ
SELECTED/MULTI PART CTRL2
VR5
VH335600
Slide Variable Resistor B 10K RS45111A9
スライドＶＲ
VOLUME 2 03
*
VR6
WG945000
Rotary Variable Resistor B 10.0K RK11K1140D
ロータリーＶＲ
SELECTED/MULTI PART CTRL3
VR7
VH335600
Slide Variable Resistor B 10K RS45111A9
スライドＶＲ
VOLUME 3 03
*
VR8
WG945000
Rotary Variable Resistor B 10.0K RK11K1140D
ロータリーＶＲ
SELECTED/MULTI PART CTRL4
VR9
VH335600
Slide Variable Resistor B 10K RS45111A9
スライドＶＲ
VOLUME 4 03
X1
V6091100
Ceramic Resonator 8.38MHz EFOMC8384T4
セラミック発振子
01
*
X1
WJ479800
Ceramic Resonator 8.38MHz EFOEC8384T4
セラミック発振子
*
WH046400
Circuit Board PNB-BLG
ＰＮＢ−ＢＬＧシート
XS6/7/8 (WG45440)(X7366C0)
*
WG977800
Circuit Board PNB-PN (with buttons)
ＰＮＢ−ＰＮシート
XS6/7/8 (WG45440)(X7366C0)
*
WG977900
Circuit Board PNB-RB
ＰＮＢ−ＲＢシート
XS6/7/8 (WG45440)(X7366C0)
--
Jumper Wire 0.55
ジャンパー線
(VA07890)
C3
UI528220
Electrolytic Cap. 220.00 10.0V
ケミコン
C4
VF611200
Monolithic Ceramic Cap. 0.100 50V Z RX TP
積層セラコン
02
-16
VF611200
Monolithic Ceramic Cap. 0.100 50V Z RX TP
積層セラコン
02
C17
VV307600
Electrolytic Cap. 47.00 10.0V RX TP
ケミコンＯＳ
03
C18
UI537100
Electrolytic Cap. 10.00 16.0V
ケミコン
01
C19
VF611200
Monolithic Ceramic Cap. 0.100 50V Z RX TP
積層セラコン
02
C20
FG644100
Ceramic Capacitor-F 0.0100 50V Z RX TP
セラコン（Ｆ）
01
C21
VF611200
Monolithic Ceramic Cap. 0.100 50V Z RX TP
積層セラコン
02
C22
UI538100
Electrolytic Cap. 100.00 16.0V
ケミコン
01
C23
VF611200
Monolithic Ceramic Cap. 0.100 50V Z RX TP
積層セラコン
02
C24
UI538100
Electrolytic Cap. 100.00 16.0V
ケミコン
01
CN1
VB390700
Base Post Connector PH 11P TE
ベースポスト
01
CN100
VV637100
Connector, FFC FM 5P TE
コネクタＦＦＣヨウ
01
CN101
VB389900
Base Post Connector PH 3P TE
ベースポスト
01
D1
VD631600
Diode 1SS133,176,HSS104
ダイオード
01
-27
VD631600
Diode 1SS133,176,HSS104
ダイオード
01
EM1
VD542700
LC Filter DSS6NF31C223Q93A
ＬＣフィルターＥＭＩ
01
-3
VD542700
LC Filter DSS6NF31C223Q93A
ＬＣフィルターＥＭＩ
01
IC1
XZ916200
IC UPD780031AYGK-N05
ＩＣ
E-PNS2a LED/SWITCH DRIVER 05
IC2
XR363A00
IC NJM3414AD
ＩＣ
OP AMP 02
J1
--
Jumper Wire 0.55
ジャンパー線
(VA07890)
J2
--
Jumper Wire 0.55
ジャンパー線
(VA07890)
LD1
V6309100
LED Orange SEL6910A TP5
ＬＥＤ
REMOTE ON/OFF 01
LD2
V6309000
LED Green SEL6710K TP5
ＬＥＤ
EFFECT BYPASS INSERTION 01
LD3
V6309000
LED Green SEL6710K TP5
ＬＥＤ
OCTAVE DOWN 01
LD4
VT022800
LED Red SEL2210R TP8
ＬＥＤS
(REC) 01
LD5
V6309000
LED Green SEL6710K TP5
ＬＥＤ
OCTAVE UP 01
LD6
V6309000
LED Green SEL6710K TP5
ＬＥＤ
ARPEGGIO ON/OFF 01
LD7
V6309000
LED Green SEL6710K TP5
ＬＥＤ
EFFECT BYPASS SYSTEM 01
LD8
V6308700
LED Green SEL2710Y TP8
ＬＥＤW
(PLAY) 01
LD9
V6309000
LED Green SEL6710K TP5
ＬＥＤ
MASTER EFFECT 01
R1
HF454100
Carbon Resistor 10.0 1/4 J AX TP
カーボン抵抗
01
-3
HF454100
Carbon Resistor 10.0 1/4 J AX TP
カーボン抵抗
01
R4
HF456100
Carbon Resistor 1.0K 1/4 J AX TP
カーボン抵抗
01
R5
HF456100
Carbon Resistor 1.0K 1/4 J AX TP
カーボン抵抗
01
R6
HF454100
Carbon Resistor 10.0 1/4 J AX TP
カーボン抵抗
01
R7
HF456100
Carbon Resistor 1.0K 1/4 J AX TP
カーボン抵抗
01
-12
HF456100
Carbon Resistor 1.0K 1/4 J AX TP
カーボン抵抗
01
R13
HB026100
Metal Film Resistor 1.0K 1/4 F AX TP
金属被膜抵抗
01
R14
HB026100
Metal Film Resistor 1.0K 1/4 F AX TP
金属被膜抵抗
01
R15
HF456100
Carbon Resistor 1.0K 1/4 J AX TP
カーボン抵抗
01
R16
HF454560
Carbon Resistor 56.0 1/4 J AX TP
カーボン抵抗
01
-19
HF454560
Carbon Resistor 56.0 1/4 J AX TP
カーボン抵抗
01
RA1
VF771900
Resistor Array RGLE8X103J
抵抗アレイ
01
-3
VF771900
Resistor Array RGLE8X103J
抵抗アレイ
01
SW1
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
F1 01
SW2
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
SF1 01
SW3
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
F2 01
SW4
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
SF2 01
SW5
VR531200
Push Switch ML1A-11JW
プッシュＳＷI
(TOP) / LOCATE 02
SW6
VR531200
Push Switch ML1A-11JW
プッシュＳＷS
(REC) 02
SW7
VV439800
Tact Switch SKQNAJ
タクトＳＷ
REMOTE ON/OFF 01
SW8
VV439800
Tact Switch SKQNAJ
タクトＳＷ
EFFECT BYPASS INSERTION 01
SW9
VV439800
Tact Switch SKQNAJ
タクトＳＷ
OCTAVE DOWN 01
SW10
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
F3 01
SW11
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
SF3 01
PNA and PNB-BLG/PNB-PN/PNB-RB
REF NO.
PART NO. DESCRIPTION
部品名
REMARKS
QTY RANK
*
: New Parts RANK: Japan only

Yamaha Motif XS Series Specifications

General

Type	Workstation Synthesizer
Sound Engine	AWM2 with Expanded Articulation
Polyphony	128 notes
Wave ROM	355MB (when converted to 16-bit linear format)
Arpeggiator	6, 000 types
Effects	Reverb, chorus, part EQ
Sequencer	16-track sequencer, 130, 000 notes
Display	320 x 240 dot backlit LCD
Connectivity	USB, MIDI In/Out/Thru
Storage	USB storage device support
Keyboard	88-key (Motif XS8), 76-key (Motif XS7), 61-key (Motif XS6)
Number of Voices	1, 024 normal voices + 64 drum kits
