Yamaha Motif XS Series User Manual

53
MOTIF XS6/MOTIF XS7/MOTIF XS8
SW12
VR531200
Push Switch ML1A-11JW
プッシュＳＷE
(REW) / 1 02
SW13
VR531200
Push Switch ML1A-11JW
プッシュＳＷA
(STOP) 02
SW14
VV439800
Tact Switch SKQNAJ
タクトＳＷ
EFFECT BYPASS SYSTEM 01
SW15
VV439800
Tact Switch SKQNAJ
タクトＳＷ
OCTAVE UP 01
SW16
VV439800
Tact Switch SKQNAJ
タクトＳＷ
ARPEGGIO ON/OFF 01
SW17
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
F4 01
SW18
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
SF4 01
SW19
VR531200
Push Switch ML1A-11JW
プッシュＳＷR
(FF) / 2 02
SW20
VR531200
Push Switch ML1A-11JW
プッシュＳＷW
(PLAY) 02
SW21
VV439800
Tact Switch SKQNAJ
タクトＳＷ
MASTER EFFECT 01
SW22
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
F5 01
SW23
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
SF5 01
SW24
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
F6 01
SW25
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
SF6 01
TA1
VJ041400
Transistor Array TD62381PG(5)
トランジスタアレイ
04
TA2
VH885000
Transistor Array TD62785PG(5)
トランジスタアレイ
04
*
VR1
WG945000
Rotary Variable Resistor B 10.0K RK11K1140D
ロータリーＶＲ
SELECTED/MULTI PART CTRL5
VR2
VH335600
Slide Variable Resistor B 10K RS45111A9
スライドＶＲ
VOLUME 5 03
*
VR3
WG945000
Rotary Variable Resistor B 10.0K RK11K1140D
ロータリーＶＲ
SELECTED/MULTI PART CTRL6
VR4
VH335600
Slide Variable Resistor B 10K RS45111A9
スライドＶＲ
VOLUME 6 03
*
VR5
WG945000
Rotary Variable Resistor B 10.0K RK11K1140D
ロータリーＶＲ
SELECTED/MULTI PART CTRL7
VR6
VH335600
Slide Variable Resistor B 10K RS45111A9
スライドＶＲ
VOLUME 7 03
*
VR7
WG945000
Rotary Variable Resistor B 10.0K RK11K1140D
ロータリーＶＲ
SELECTED/MULTI PART CTRL8
VR8
VH335600
Slide Variable Resistor B 10K RS45111A9
スライドＶＲ
VOLUME 8 03
X1
V6091100
Ceramic Resonator 8.38MHz EFOMC8384T4
セラミック発振子
01
*
X1
WJ479800
Ceramic Resonator 8.38MHz EFOEC8384T4
セラミック発振子
*
WH011200
Circuit Board PNC (with buttons)
ＰＮＣシート
XS6/XS7/XS8 (X7367C0)
--
Jumper Wire 0.55
ジャンパー線
(VA07890)
C3
FG644100
Ceramic Capacitor-F 0.0100 50V Z RX TP
セラコン（Ｆ）
01
C4
UI528220
Electrolytic Cap. 220.00 10.0V
ケミコン
C5
VF611200
Monolithic Ceramic Cap. 0.100 50V Z RX TP
積層セラコン
02
-8
VF611200
Monolithic Ceramic Cap. 0.100 50V Z RX TP
積層セラコン
02
C9
FG644100
Ceramic Capacitor-F 0.0100 50V Z RX TP
セラコン（Ｆ）
01
C10
VF611200
Monolithic Ceramic Cap. 0.100 50V Z RX TP
積層セラコン
02
C11
UI528220
Electrolytic Cap. 220.00 10.0V
ケミコン
C12
UI528220
Electrolytic Cap. 220.00 10.0V
ケミコン
C13
VF611200
Monolithic Ceramic Cap. 0.100 50V Z RX TP
積層セラコン
02
CN1
VB390700
Base Post Connector PH 11P TE
ベースポスト
01
D1
VD631600
Diode 1SS133,176,HSS104
ダイオード
01
-72
VD631600
Diode 1SS133,176,HSS104
ダイオード
01
EC1
V6341400
Rotary Encoder XRE0121PVB15FINB1
ロータリーエンコーダ
Data dial 01
EM1
VD542700
LC Filter DSS6NF31C223Q93A
ＬＣフィルターＥＭＩ
01
EM2
VD542700
LC Filter DSS6NF31C223Q93A
ＬＣフィルターＥＭＩ
01
IC1
XZ916200
IC UPD780031AYGK-N05
ＩＣ
E-PNS2a LED/SWITCH DRIVER 05
J1
--
Jumper Wire 0.55
ジャンパー線
(VA07890)
LD1
V6309000
LED Green SEL6710K TP5
ＬＥＤ
VOICE 01
LD2
V6309000
LED Green SEL6710K TP5
ＬＥＤ
SEQUENCER SONG 01
LD3
V6309000
LED Green SEL6710K TP5
ＬＥＤ
INTEGRATED SAMPLING 01
LD4
V6309000
LED Green SEL6710K TP5
ＬＥＤ
FILE 01
LD5
V6309000
LED Green SEL6710K TP5
ＬＥＤ
EDIT / COMPARE 01
LD6
V6309000
LED Green SEL6710K TP5
ＬＥＤ
PERFORM 01
LD7
V6309000
LED Green SEL6710K TP5
ＬＥＤ
SEQUENCER PATTERN 01
LD8
V6309000
LED Green SEL6710K TP5
ＬＥＤ
SEQUENCER MIXING 01
LD9
V6309100
LED Orange SEL6910A TP5
ＬＥＤ
MASTER 01
LD10
V6309000
LED Green SEL6710K TP5
ＬＥＤ
SEQ SETUP 01
LD11
V6309000
LED Green SEL6710K TP5
ＬＥＤ
UTILITY 01
LD12
V6309000
LED Green SEL6710K TP5
ＬＥＤ
COMMON EDIT 01
LD13
V6309000
LED Green SEL6710K TP5
ＬＥＤ
PRE1 / PIANO 01
LD14
V6309000
LED Green SEL6710K TP5
ＬＥＤ
USER1 / SYN LEAD 01
LD15
V6309000
LED Green SEL6710K TP5
ＬＥＤ
A01
LD16
V6309000
LED Green SEL6710K TP5
ＬＥＤ
101
LD17
V6309000
LED Green SEL6710K TP5
ＬＥＤ
901
LD18
V6309000
LED Green SEL6710K TP5
ＬＥＤ
PRE2 / KEYBOARD 01
LD19
V6309000
LED Green SEL6710K TP5
ＬＥＤ
USER2 / PADS/CHOIRS 01
LD20
V6309000
LED Green SEL6710K TP5
ＬＥＤ
B01
LD21
V6309000
LED Green SEL6710K TP5
ＬＥＤ
201
LD22
V6309000
LED Green SEL6710K TP5
ＬＥＤ
10 01
LD23
V6309000
LED Green SEL6710K TP5
ＬＥＤ
PRE3 / ORGAN 01
LD24
V6309000
LED Green SEL6710K TP5
ＬＥＤ
USER3 / SYN COMP 01
PNB-BLG/PNB-PN/PNB-RB and PNC
REF NO.
PART NO.
DESCRIPTION
部品名
REMARKS
QTY RANK
*
: New Parts RANK: Japan only

Yamaha Motif XS Series Specifications

General

Type	Workstation Synthesizer
Sound Engine	AWM2 with Expanded Articulation
Polyphony	128 notes
Wave ROM	355MB (when converted to 16-bit linear format)
Arpeggiator	6, 000 types
Effects	Reverb, chorus, part EQ
Sequencer	16-track sequencer, 130, 000 notes
Display	320 x 240 dot backlit LCD
Connectivity	USB, MIDI In/Out/Thru
Storage	USB storage device support
Keyboard	88-key (Motif XS8), 76-key (Motif XS7), 61-key (Motif XS6)
Number of Voices	1, 024 normal voices + 64 drum kits
