Yamaha Motif XS Series User Manual

54
MOTIF XS6/MOTIF XS7/MOTIF XS8
LD25
V6309000
LED Green SEL6710K TP5
ＬＥＤ
C01
LD26
V6309000
LED Green SEL6710K TP5
ＬＥＤ
301
LD27
V6309000
LED Green SEL6710K TP5
ＬＥＤ
11 01
LD28
V6309000
LED Green SEL6710K TP5
ＬＥＤ
PRE4 / GUITAR 01
LD29
V6309000
LED Green SEL6710K TP5
ＬＥＤ
GM / CHROMATIC PERCUSSION
01
LD30
V6309000
LED Green SEL6710K TP5
ＬＥＤ
D
01
LD31
V6309000
LED Green SEL6710K TP5
ＬＥＤ
4
01
LD32
V6309000
LED Green SEL6710K TP5
ＬＥＤ
12
01
LD33
V6309000
LED Green SEL6710K TP5
ＬＥＤ
PRE5 / BASS
01
LD34
V6309000
LED Green SEL6710K TP5
ＬＥＤ
GM DR / DRUM/PERCUSSION
01
LD35
V6309000
LED Green SEL6710K TP5
ＬＥＤ
E
01
LD36
V6309000
LED Green SEL6710K TP5
ＬＥＤ
5
01
LD37
V6309000
LED Green SEL6710K TP5
ＬＥＤ
13
01
LD38
V6309000
LED Green SEL6710K TP5
ＬＥＤ
PRE6 / STRINGS
01
LD39
V6309000
LED Green SEL6710K TP5
ＬＥＤ
PRE DR / SOUND EFX
01
LD40
V6309000
LED Green SEL6710K TP5
ＬＥＤ
F
01
LD41
V6309000
LED Green SEL6710K TP5
ＬＥＤ
6
01
LD42
V6309000
LED Green SEL6710K TP5
ＬＥＤ
14
01
LD43
V6309000
LED Green SEL6710K TP5
ＬＥＤ
PRE7 / BRASS
01
LD44
V6309000
LED Green SEL6710K TP5
ＬＥＤ
USE DR / MUSICAL EFX
01
LD45
V6309000
LED Green SEL6710K TP5
ＬＥＤ
G
01
LD46
V6309000
LED Green SEL6710K TP5
ＬＥＤ
7
01
LD47
V6309000
LED Green SEL6710K TP5
ＬＥＤ
15
01
LD48
V6309000
LED Green SEL6710K TP5
ＬＥＤ
PRE8 / SAX/WOODWIND
01
LD49
V6309000
LED Green SEL6710K TP5
ＬＥＤ
ETHNIC
01
LD50
V6309000
LED Green SEL6710K TP5
ＬＥＤ
H
01
LD51
V6309000
LED Green SEL6710K TP5
ＬＥＤ
8
01
LD52
V6309000
LED Green SEL6710K TP5
ＬＥＤ
16
01
LD53
V6309100
LED Orange SEL6910A TP5
ＬＥＤ
PROGRAM
01
LD54
V6309100
LED Orange SEL6910A TP5
ＬＥＤ
CATEGORY SEARCH
01
LD55
V6309100
LED Orange SEL6910A TP5
ＬＥＤ
PERFORMANCE CONTROL
01
LD56
V6309100
LED Orange SEL6910A TP5
ＬＥＤ
MUTE
01
LD57
V6309100
LED Orange SEL6910A TP5
ＬＥＤ
TRACK
01
LD58
V6309100
LED Orange SEL6910A TP5
ＬＥＤ
SOLO
01
R1
HF454100
Carbon Resistor 10.0 1/4 J AX TP
カーボン抵抗
01
-3
HF454100
Carbon Resistor 10.0 1/4 J AX TP
カーボン抵抗
01
R4
HF456100
Carbon Resistor 1.0K 1/4 J AX TP
カーボン抵抗
01
R5
HF454560
Carbon Resistor 56.0 1/4 J AX TP
カーボン抵抗
01
-12
HF454560
Carbon Resistor 56.0 1/4 J AX TP
カーボン抵抗
01
RA1
VF771900
Resistor Array RGLE8X103J
抵抗アレイ
01
-3
VF771900
Resistor Array RGLE8X103J
抵抗アレイ
01
SW1
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
DEC/NO
01
SW2
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ<
01
SW3
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
EXIT
01
SW4
VZ085500
Tact Switch SKQNAMD010
タクトＳＷB
01
SW5
VZ085500
Tact Switch SKQNAMD010
タクトＳＷN
01
SW6
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
INC/YES
01
SW7
VZ085500
Tact Switch SKQNAMD010
タクトＳＷM
01
SW8
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
ENTER / EXECUTE
01
SW9
VV439800
Tact Switch SKQNAJ
タクトＳＷ
VOICE
01
SW10
VV439800
Tact Switch SKQNAJ
タクトＳＷ
SEQUENCER SONG
01
SW11
VV439800
Tact Switch SKQNAJ
タクトＳＷ
INTEGRATED SAMPLING
01
SW12
VV439800
Tact Switch SKQNAJ
タクトＳＷ
FILE
01
SW13
VV439800
Tact Switch SKQNAJ
タクトＳＷ
EDIT / COMPARE
01
SW14
VV439800
Tact Switch SKQNAJ
タクトＳＷ
PERFORM
01
SW15
VV439800
Tact Switch SKQNAJ
タクトＳＷ
SEQUENCER PATTERN
01
SW16
VV439800
Tact Switch SKQNAJ
タクトＳＷ
SEQUENCER MIXING
01
SW17
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
JOB
01
SW18
VV439800
Tact Switch SKQNAJ
タクトＳＷ
MASTER
01
SW19
VV439800
Tact Switch SKQNAJ
タクトＳＷ
SEQ SETUP
01
SW20
VV439800
Tact Switch SKQNAJ
タクトＳＷ
UTILITY
01
SW21
VZ085500
Tact Switch SKQNAMD010
タクトＳＷ
STORE/SET LOCATE
01
SW22
VV439800
Tact Switch SKQNAJ
タクトＳＷ
COMMON EDIT
01
SW23
VV439800
Tact Switch SKQNAJ
タクトＳＷ
PRE1 / PIANO
01
SW24
VV439800
Tact Switch SKQNAJ
タクトＳＷ
USER1 / SYN LEAD
01
SW25
VV439800
Tact Switch SKQNAJ
タクトＳＷ
A
01
SW26
VV439800
Tact Switch SKQNAJ
タクトＳＷ
1
01
SW27
VV439800
Tact Switch SKQNAJ
タクトＳＷ
9
01
SW28
VV439800
Tact Switch SKQNAJ
タクトＳＷ
PRE2 / KEYBOARD
01
SW29
VV439800
Tact Switch SKQNAJ
タクトＳＷ
USER2 / PADS/CHOIRS
01
PNC
REF NO.
PART NO. DESCRIPTION
部品名
REMARKS
QTY RANK
*
: New Parts RANK: Japan only

Yamaha Motif XS Series Specifications

General

Type	Workstation Synthesizer
Sound Engine	AWM2 with Expanded Articulation
Polyphony	128 notes
Wave ROM	355MB (when converted to 16-bit linear format)
Arpeggiator	6, 000 types
Effects	Reverb, chorus, part EQ
Sequencer	16-track sequencer, 130, 000 notes
Display	320 x 240 dot backlit LCD
Connectivity	USB, MIDI In/Out/Thru
Storage	USB storage device support
Keyboard	88-key (Motif XS8), 76-key (Motif XS7), 61-key (Motif XS6)
Number of Voices	1, 024 normal voices + 64 drum kits
