Yamaha Motif XS Series User Manual

12
11
10
9
8
7
6
5
4
3
2
1
ABCDEFGH I JKLMNOPQ
12
11
10
9
8
7
6
5
4
3
2
1
ABCDEFGH I JKLMNOPQ
MOTIF XS6/MOTIF XS7/MOTIF XS8
MOTIF XS6/MOTIF XS7/MOTIF XS8
MOTIF XS6/MOTIF XS7/MOTIF XS8
MOTIF XS6/MOTIF XS7/MOTIF XS8 OVERALL CIRCUIT DIAGRAM 4/11 (DM 4/4,
JKAN-LC
)
<Page 5>
DM 4/4
28CC1-2001007282 -002 1
Note : See parts list for details of circuit board component parts.
注： シートの部品詳細はパーツリストをご参照ください。
28CC1-2001003867-0080 128CC1-2001003867-0020
JKAN-LC
LCD
CPU
(RISC PROCES(X6669A0))
SDRAM 512M
SDRAM 512M
LCDC
DRAM 16M
OP AMP
INVERTER
INVERTER
INVERTER
INVERTER
CPU(USB)
to JKAN-ML - CN300 <Page 11 P-2>
2SC4672 (V9065800)
TRANSISTOR
JKAN-LC: TR200,201
1: BASE
2: COLLECTOR
3: EMITTER
1
3
2
1
2
3
<P.3 DM2/4 K-7>
<P.3 DM2/4 K-7>
<P.3 DM2/4 J-7>
<P.3 DM2/4 J-7>
<P.3 DM2/4 F-2>
<P.3 DM2/4 J-7>
<P.3 DM2/4 L-3>
<P.3 DM2/4 J-7>
<P.3 DM2/4 J-7>
<P.3 DM2/4 J-7>
<P.3 DM2/4 J-7>
<P.3 DM2/4 J-7>
<P.3 DM2/4 D-2>
Quartz
crystal
<P.3 DM2/4 D-2>
<P.3 DM2/4 D-4>
<P.3 DM2/4 L-3>
<P.2 DM2/4 L-3>
<P.2 DM2/4 L-4>
: Ceramic Capacitor (chip)
: Mylar Capacitor (chip) （チップマイラーコンデンサー）
（チップセラミックコンデンサー）
: Metal Film Resistor (chip) （チップ金属被膜抵抗）
USB
TO HOST
LCD CONTRAST
2SC2412K(VV556400)
2SA1037AK(VV556500)
TRANSISTOR
DM: TR822
DM: TR821
1
1
2
2
3
3
1: EMITTER
2: BASE
3: COLLECTOR
USB Micom(mask)
Not installed
<Top-view>
Conduction point
Conduction point

Yamaha Motif XS Series Specifications

General

Type	Workstation Synthesizer
Sound Engine	AWM2 with Expanded Articulation
Polyphony	128 notes
Wave ROM	355MB (when converted to 16-bit linear format)
Arpeggiator	6, 000 types
Effects	Reverb, chorus, part EQ
Sequencer	16-track sequencer, 130, 000 notes
Display	320 x 240 dot backlit LCD
Connectivity	USB, MIDI In/Out/Thru
Storage	USB storage device support
Keyboard	88-key (Motif XS8), 76-key (Motif XS7), 61-key (Motif XS6)
Number of Voices	1, 024 normal voices + 64 drum kits
