SERVO SELECTION AND DATA SHEETS
5.4.1 Servomotor Dimensional Drawings
268
2) The dimensional drawings of the SGMP Servomotors are broadly grouped into the fol-
lowing four categories.
a) Incremental encoder, no brake (from page 269)
b) Incremental encoder, with brake (from page 274)
c) Absolute encoder, no brake (from page 279)
d) Absolute encoder, with brake (from page 283)
Motor capacities are available as 100 W (0.13 HP), 200 W (0.27 HP), 300 W (0.40 HP) ,
400 W (0.53 HP), 750 W (1.01 HP). These are grouped into three categories, as follows:
• 100W (0.13 HP)
• 200W (0.27 HP), 300W (0.40 HP), 400W (0.53 HP)
• 750W (1.01 HP)
