YASKAWA SGDA series User Manual

5.4Σ -Series Dimensional Drawings
277
• 750 W (1.01HP)
Encoder Lead
Encoder Plug
Motor Plug
Motor Lead
Sealant
Incremental Encoder
Holding Brake (deenergization
operation)
Voltage: 90 VDC
Brake holding torque = motor rated
torque
Cross-section Y-Y
Hex. nut
17 (0.67)
(Φ0.0016)
MTG Holes
Screw
Shaft end screw hole
(SGMP-08A316B, with key type only)
Type
SGMP-
QK U W T Screw
Dimen-
sions
Output
W
(HP)
Approx.
mass
kg
(lb)
Allowable
radial
load
N (lb)
Allowable
thrust
load
N (lb)
08A312B No key

750
(1 01)
6..1
(
13
)
392 (88) 147 (33)
08A314B
22
(0 8 )
3 (0.12) 5 (0.20) 5 (0.20)
(1.01) (13.45)
(
)
(
)
08A316B
(0.87)
()
()
()
M5,
depth 8
(0.31)
Note 1) The detector uses an incremental encoder 2048 P/R.
2) Type “A” indicates 200 V specification.
3) “08A314B” and “08A316B” have a keyed shaft. The keyway complies with JIS B
1301-1976 (precision).
A straight key is supplied.
5
