Yealink SIP-T46G Administrator's Guide

Getting Started
9
AC Power
To connect the AC power and network:
1. Connect the DC plug of the power adapter to the DC5V port on the IP phones and
connect the other end of the power adapter into an electrical power outlet.
2. Connect the supplied Ethernet cable between the Internet port on the IP phones
and the Internet port in your network or switch/hub device port.
Power over Ethernet
Using a regular Ethernet cable, the IP phones can be powered from a PoE (IEEE 802.3af)
compliant switch or hub.
To connect the PoE:
1. Connect the Ethernet cable between the Internet port on the IP phones and an
available port on the in-line power switch/hub.
Note
If in-line power is provided, you do not need to connect the AC adapter. Make sure the
Ethernet cable and switch/hub is PoE compliant.
The IP phones can also share the network with other network devices such as a PC
(personal computer). It is an optional connection.
Important! Do not unplug or remove power while the IP phones are updating firmware
and configurations.

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
