Yealink SIP-T46G Administrator's Guide

Configuring Basic Features
75
http://<phoneIPAddress>/servlet
?p=features-general&q=load
To configure the return code when refusing a call via web user interface:
1. Click on Features->General Information.
2. Select the desired value from the pull-down list of Return Code Refuse.
3. Click Confirm to accept the change.
Early media refers to media (e.g., audio and video) played to the caller before a SIP
call is actually established. Current implementation supports early media through the
183 message. When the caller receives a 183 message with SDP before the call is
established, a media channel is established. This channel is used to provide the early
media stream to the caller.
The 180 ring workaround feature defines whether to deal with the 180 message
received after the 183 message. When the caller receives a 183 message, it suppresses
any local ringback tone and begins to play the media received. 180 ring workaround
allows the IP phones to resume and play the local ringback tone upon a subsequent 180
message received.
Procedure
180 ring workaround can be configured using the configuration files or locally.
Configuration File
<y000000000028>.cfg
Configure the 180 ring

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
