Yealink SIP-T46G Administrator's Guide

Administrator’s Guide for SIP-T46G IP Phone
56
Procedure
Missed call log can be configured using the configuration files or locally.
Configuration File
<MAC>.cfg
Configure the missed call log
feature.
For more information, refer to
Missed Call Log on page 254.
Local
Web User Interface
Configure the missed call log
feature.
Navigate to:
http://<phoneIPAddress>/servlet
?p=account-basic&q=load&acc
=0
To configure missed call log via web user interface:
1. Click on Account.
2. Select the desired account from the pull-down list of Account.
3. Click on Basic.
4. Select the desired value from the pull-down list of Missed Call Log.
5. Click Confirm to accept the change.
The IP phone maintains a local directory. The local directory can store up to 1000
contacts. When adding a contact to the local directory, you can specify the account, ring
tone and group for the contact in addition to name and phone numbers. The local
directory can add new groups and add new contacts to different groups. The contacts
can be created either one by one or in batch using a contact file. For more information
on the contact file, refer to Local Contact File on page 213.

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
