Yealink SIP-T46G Administrator's Guide

Administrator’s Guide for SIP-T46G IP Phone
404
The following figure illustrates successful call forwarding between Yealink SIP IP phones
in which User B has enabled no answer call forward. The incoming call is forwarded to
User C when User B does not answer the incoming call after a period of time. In this call
flow scenario, the end users are User A, User B, and User C. They are all using Yealink
SIP IP phones, which are connected via an IP network.
The call flow scenario is as follows:
1. User B enables no answer call forward, and the destination number is User C.
2. User A calls User B.
3. User B does not answer the incoming call.
4. User B forwards the incoming call to User C.
5. User C answers the call.
Call is established between User A and User C.
User A Proxy Server User B User C
F1. INVITE B
F2. INVITE B
F3. 180 Ringing
F8. ACK
F9. INVITE C
F10. INVITE C
F11. 180 Ringing
F12. 180 Ringing
F13. 200 OK
F14. 200 OK
F15. ACK
F16. ACK
F4. 180 Ringing
F5. 302 Move Temporarily
F6. ACK
F7. 302 Move Temporarily
2-way RTP channel established

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
