Yealink SIP-T46G Administrator's Guide

Administrator’s Guide for SIP-T46G IP Phone
214
<group display_name=‖‖ ring=‖‖/>
Where:
display_name=‖‖ specifies the name of the group.
ring=‖‖ specifies the desired ring tone for this group.
4. Specify the values within double quotes.
5. Place this file to the root directory of the provisioning server.
The following is an example of a local contact file:
<root_contact>
<contact display_name="John" office_number="1001"
mobile_number="12345678910" other_number="" line="0" ring="Auto"
group_id_name="All Contacts" default_photo=""/>
<contact display_name="Alice" office_number="1002" mobile_number=""
other_number="" line="2" ring=”Resource:Ring2.wav”
group_id_name="Friend" default_photo=""/>
</root_contact>
<root_group>
<group display_name=”Friend” ring=””/>
<group display_name=”Family” ring=”Resource:Ring1.wav”/>
</root_group>
The IP phone can access 5 remote phonebooks. You can customize the remote XML
phonebook for the IP phone as required. Before specifying the access URL of the remote
phonebook in the configuration files, you need to create a remote XML phonebook and
then place it to the provisioning server.
When creating an XML phonebook, remember the following:
 <YealinkIPPhoneDirectory> indicates the start of a phonebook and
</YealinkIPPhoneDirectory> indicates the end of a phonebook.
 <DirectoryEntry> indicates the start of a contact and </DirectoryEntry> indicates
the end of a contact.
Procedure
Use the following procedures to customize an XML phonebook.
Customizing an XML phonebook:
1. Open the template file using an ASCII editor.
2. For each contact that you want to add, add the following strings to the IP
phonebook. Each starts on a separate line:

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
