Yealink SIP-T46G Administrator's Guide

Getting Started
23
Procedure
The transmission method of Ethernet port can be configured using the configuration files
or locally.
Configuration File
<y000000000028>.cfg
Configure the transmission
method of Ethernet port.
For more information, refer to
Internet and PC Ports Negotiation
on page 236.
Local
Web User Interface
Configure the transmission
method of Ethernet port.
Navigate to:
http://<phoneIPAddress>/servlet
?p=network-adv&q=load
To configure the transmission method of Ethernet port via web user interface:
1. Click on Network->Advanced.
2. Select the desired value from the pull-down list of WAN Port Link.
3. Select the desired value from the pull-down list of PC Port Link.
4. Click Confirm to accept the change.
Regular expression, often called a pattern, is an expression that specifies a set of strings.
A regular expression provides a concise and flexible means to ―match‖ (specify and
recognize) strings of text, such as particular characters, words, or patterns of characters.
Regular expression is used by many text editors, utilities, and programming languages

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
