Yealink SIP-T46G Administrator's Guide

Administrator’s Guide for SIP-T46G IP Phone
372
The following figure illustrates the scenario of a successful call. In this scenario, the two
end users are User A and User B. User A and User B are located at the Yealink SIP IP
phones.
The call flow scenario is as follows:
1. User A calls User B.
2. User B answers the call.
3. User B hangs up.
User A Proxy Server User B
F1. INVITE B
F2. INVITE B
F3. 100 Trying
F9. ACK
F10. ACK
F5. 180 Ringing
2-way RTP channel established
F8. 200 OK
F7. 200 OK
F6. 180 Ringing
F4. 100 Trying
F11. BYE
F12. BYE
F13. 200 OK
F14. 200 OK

Yealink SIP-T46G Specifications

General

Backlight	Yes
Power requirements	100-240V, DC 5V
Touchscreen	-
Display diagonal	4.3 \
Display resolution	480 x 272 pixels
Lines quantity	- lines
Phonebook capacity	1000 entries
Number of VoIP accounts	6
Voice codecs	G.711, G.722, G.723, G.726, G.729A, G.729B
Bluetooth	No
RJ-9 ports quantity	2
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Storage temperature (T-T)	-10 - 50 °C
Operating relative humidity (H-H)	10 - 95 %
Handset type	Wired handset
Product type	IP Phone
Product color	Black
Number of handles included	1 pc(s)

Weight and Dimensions

Depth	185 mm
Width	244 mm
Height	213 mm
