TG Series User Guide
17/86
Ground Connection
WARNING
Proper grounding (connection to ground) is very important to reduce the risk to the user of
electrocution or protect the TG gateway from the bad effects of external noise in the case of
a lightning strike.
A permanent connection between ground and the ground terminal of the TG gateway must
be made.
Procedure
1. Tighten the provided screw stud into the Grounding port on TG gateway.
2. Insert a grounding wire (user supplied).
3. Tighten the provided screw nut.
4. Attach the grounding wire to the grounding terminal.
