6-49
IM DL850-03EN
Specifications
CAN Bus Monitor Module (720240) Specification
Item Specifications
Standard operating
condition
Ambient temperature: 23±5°C
Ambient humidity: 20 to 80% RH
Number of input ports 2
Maximum sample rate 100 kS/s
Input format Isolated unbalanced
Maximum input voltage –3 to +10 V (between CAN_H and GND or CAN_L and GND)
Maximum allowable
common mode voltage
42 V (DC+ACpeak) (CAT II, 30 Vrms)
Input connector D-sub 9 pin (male)
Terminator Internal, can be enabled or disabled for each port
Supported protocol Physical layer: ISO-11898 (High Speed Communication)
Supported bit rates
1
10 kbps, 20 kbps, 33.3 kbps, 50 kbps, 62.5 kbps, 66.7 kbps, 83.3 kbps, 100 kbps, 125 kbps,
250 kbps, 500 kbps, 800 kbps, 1 Mbps
LED display Illuminates to indicate that the terminator is enabled
Number of sub channels 16 sub channels/ports (60 for firmware versions 1.20 and later)
One shot output Frames can be output in single shots
Terminator resistance
(when the terminator is
enabled)
110 to 130 Ω
A/D converter resolution
(when Value Type is set to
Float
2
)
16 bits, 2400 LSB/div
1 Low-speed CAN at low-speed transceiver levels is not supported. The 100 kbps covers firmware versions 1.30 and later of the
DL850/DL850V.
2 Applies to modules whose firmware version is 1.20 and later
6.13 Module Specifications
