6-50
IM DL850-03EN
CAN & LIN Bus Monitor Module (720241) Specification
Item Specifications
Standard operating
condition
Ambient temperature: 23±5°C
Ambient humidity: 20 to 80% RH
Number of input ports CAN port: 1. LIN port: 1.
Maximum sample rate 100 kS/s
Input format Isolated unbalanced
CAN port specifications
Item Specifications
Maximum input voltage –3 to +10 V (between CAN_H and GND or CAN_L and GND)
Maximum allowable
common mode voltage
42 V (DC+ACpeak) (CAT II, 30 Vrms)
Input connector D-sub 9 pin (male)
Terminator Internal, can be enabled or disabled
Terminator resistance
(when the terminator is
enabled)
110 to 130 Ω
LED display Illuminates to indicate that the terminator is enabled
Supported protocol Physical layer: ISO-11898 (High Speed Communication)
Supported bit rates
1
10 kbps, 20 kbps, 33.3 kbps, 50 kbps, 62.5 kbps, 66.7 kbps, 83.3 kbps, 100 kbps, 125 kbps,
250 kbps, 500 kbps, 800 kbps, 1 Mbps
Supported data length 4 bytes maximum
Number of sub channels 60 sub channels
One shot output Frames can be output in single shots
A/D converter resolution
(when Value Type is set to
Float)
16 bits, 2400 LSB/div
1
Low-speed CAN at low-speed transceiver levels is not supported.
LIN port specifications
Item Specifications
Maximum input voltage –0.3 to +18 V (between LIN.VBAT and GND)
Maximum allowable
common mode voltage
30 Vrms (CAT I and II)
Input connector D-sub 9 pin (male)
Supported protocol Physical layer: : Complies with ISO9141
Supported bit rates 2400bps, 9600bps, 19200bps
Supported data length 4 bytes maximum
Number of sub channels 60 sub channels
Supported check sums Standard check sum, extended check sum
6.13 Module Specifications
