YOKOGAWA DL850 ScopeCorder User Manual

App-4
IM DL850-03EN
(Continued from previous page)
Record Length
2.5 Mpoint 5 Mpoint 10 Mpoint 25 Mpoint 50 Mpoint
Time/div Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
6 h 10 2.16 M 20 4.32 M 20 4.32 M 100 21.6 M 200 43.2 M
7 h 5 1.26 M 10 2.52 M 20 5.04 M 50 12.6 M 100 25.2 M
8 h 5 1.44 M 10 2.88 M 20 5.76 M 50 14.4 M 100 28.8 M
9 h 5 1.62 M 10 3.24 M 20 6.48 M 50 16.2 M 100 32.4 M
10 h 5 1.8 M 10 3.6 M 20 7.2 M 50 18 M 100 36 M
12 h 5 2.16 M 10 4.32 M 20 8.64 M 50 21.6 M 100 43.2 M
1 day 5 4.32 M 10 8.64 M 20 17.28 M 50 43.2 M
2 days 5 8.64 M 10 17.28 M 20 34.56 M
3 days 5 12.96 M 10 25.92 M
When the time axis setting is 100 ms or greater (the settings surrounded by bold lines) and the trigger mode is Auto or Auto Level,
waveforms are displayed in roll mode.
When the Record Length Is 100 Mpoint, 250 Mpoint, 500 Mpoint, 1 Gpoint, or 2 Gpoint
Record Length
100 Mpoint 250 Mpoint 500 Mpoint 1 Gpoint 2 Gpoint
Time/div Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
100 ns 100 M 100 100 M 100 100 M 100 100 M 100 100 M 100
200 ns 100 M 200 100 M 200 100 M 200 100 M 200 100 M 200
500 ns 100 M 500 100 M 500 100 M 500 100 M 500 100 M 500
1 μs 100 M 1 k 100 M 1 k 100 M 1 k 100 M 1 k 100 M 1 k
2 μs 100 M 2 k 100 M 2 k 100 M 2 k 100 M 2 k 100 M 2 k
5 μs 100 M 5 k 100 M 5 k 100 M 5 k 100 M 5 k 100 M 5 k
10 μs 100 M 10 k 100 M 10 k 100 M 10 k 100 M 10 k 100 M 10 k
20 μs 100 M 20 k 100 M 20 k 100 M 20 k 100 M 20 k 100 M 20 k
50 μs 100 M 50 k 100 M 50 k 100 M 50 k 100 M 50 k 100 M 50 k
100 μs 100 M 100 k 100 M 100 k 100 M 100 k 100 M 100 k 100 M 100 k
200 μs 100 M 200 k 100 M 200 k 100 M 200 k 100 M 200 k 100 M 200 k
500 μs 100 M 500 k 100 M 500 k 100 M 500 k 100 M 500 k 100 M 500 k
1 ms 100 M 1 M 100 M 1 M 100 M 1 M 100 M 1 M 100 M 1 M
2 ms 100 M 2 M 100 M 2 M 100 M 2 M 100 M 2 M 100 M 2 M
5 ms 100 M 5 M 100 M 5 M 100 M 5 M 100 M 5 M 100 M 5 M
10 ms 100 M 10 M 100 M 10 M 100 M 10 M 100 M 10 M 100 M 10 M
20 ms 100 M 20 M 100 M 20 M 100 M 20 M 100 M 20 M 100 M 20 M
50 ms 100 M 50 M 100 M 50 M 100 M 50 M 100 M 50 M 100 M 50 M
100 ms 100 M 100 M 100 M 100 M 100 M 100 M 100 M 100 M 100 M 100 M
200 ms 50 M 100 M 100 M 200 M 100 M 200 M 100 M 200 M 100 M 200 M
500 ms 20 M 100 M 50 M 250 M 100 M 500 M 100 M 500 M 100 M 500 M
1 s 10 M 100 M 20 M 200 M 50 M 500 M 100 M 1 G 100 M 1 G
2 s 5 M 100 M 10 M 200 M 20 M 400 M 50 M 1 G 100 M 2 G
3 s 2 M 60 M 5 M 150 M 10 M 300 M 20 M 600 M 50 M 1.5 G
4 s 2 M 80 M 5 M 200 M 10 M 400 M 20 M 800 M 50 M 2 G
5 s 2 M 100 M 5 M 250 M 10 M 500 M 20 M 1 G 20 M 1 G
6 s 1 M 60 M 2 M 120 M 5 M 300 M 10 M 600 M 20 M 1.2 G
8 s 1 M 80 M 2 M 160 M 5 M 400 M 10 M 800 M 20 M 1.6 G
10 s 1 M 100 M 2 M 200 M 5 M 500 M 10 M 1 G 20 M 2 G
20 s 500 k 100 M 1 M 200 M 2 M 400 M 5 M 1 G 10 M 2 G
30 s 200 k 60 M 500 k 150 M 1 M 300 M 2 M 600 M 5 M 1.5 G
When the time axis setting is 100 ms or greater (the settings surrounded by bold lines) and the trigger mode is Auto or Auto Level,
waveforms are displayed in roll mode.
(Continued on next page)
Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate

YOKOGAWA DL850 ScopeCorder Specifications

General

Maximum Sampling Rate	100 MS/s
Power Supply	100 to 240 VAC, 50/60 Hz
Resolution	16-bit
Operating Temperature	5 to 40°C
Bandwidth	20 MHz
Input Types	Voltage, Temperature, Strain, Acceleration, Frequency, Logic, Current
Interfaces	Ethernet, USB, GP-IB
Trigger Modes	Edge, Window, Pattern
Number of Channels	Up to 128 (with multiple input modules)
Memory Capacity	Up to 2 G points (with /M4 option)
