(Continued from previous page)
Record Length
100 Mpoint 250 Mpoint 500 Mpoint 1 Gpoint 2 Gpoint
Time/div Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
1 min 100 k 60 M 200 k 120 M 500 k 300 M 1 M 600 M 2 M 1.2 G
2 min 50 k 60 M 200 k 240 M 200 k 240 M 500 k 600 M 1 M 1.2 G
3 min 50 k 90 M 100 k 180 M 200 k 360 M 500 k 900 M 1 M 1.8 G
4 min 20 k 48 M 100 k 240 M 200 k 480 M 200 k 480 M 500 k 1.2 G
5 min 20 k 60 M 50 k 150 M 100 k 300 M 200 k 600 M 500 k 1.5 G
6 min 20 k 72 M 50 k 180 M 100 k 360 M 200 k 720 M 500 k 1.8 G
7 min 20 k 84 M 50 k 210 M 100 k 420 M 200 k 840 M 200 k 840 M
8 min 20 k 96 M 50 k 240 M 100 k 480 M 200 k 960 M 200 k 960 M
9 min 10 k 54 M 20 k 108 M 50 k 270 M 100 k 540 M 200 k 1.08 G
10 min 10 k 60 M 20 k 120 M 50 k 300 M 100 k 600 M 200 k 1.2 G
12 min 10 k 72 M 20 k 144 M 50 k 360 M 100 k 720 M 200 k 1.44 G
15 min 10 k 90 M 20 k 180 M 50 k 450 M 100 k 900 M 200 k 1.8 G
30 min 5 k 90 M 10 k 180 M 20 k 360 M 50 k 900 M 100 k 1.8 G
1 h 2 k 72 M 5 k 180 M 10 k 360 M 20 k 720 M 50 k 1.8 G
2 h 1 k 72 M 2 k 144 M 5 k 360 M 10 k 720 M 20 k 1.44 G
3 h 500 54 M 2 k 216 M 2 k 216 M 5 k 540 M 10 k 1.08 G
4 h 500 72 M 1 k 144 M 2 k 288 M 5 k 720 M 10 k 1.44 G
5 h 500 90 M 1 k 180 M 2 k 360 M 5 k 900 M 10 k 1.8 G
6 h 200 43.2 M 1 k 216 M 2 k 432 M 2 k 432 M 5 k 1.08 G
7 h 200 50.4 M 500 126 M 1 k 252 M 2 k 504 M 5 k 1.26 G
8 h 200 57.6 M 500 144 M 1 k 288 M 2 k 576 M 5 k 1.44 G
9 h 200 64.8 M 500 162 M 1 k 324 M 2 k 648 M 5 k 1.62 G
10 h 200 72 M 500 180 M 1 k 360 M 2 k 720 M 5 k 1.8 G
12 h 200 86.4 M 500 216 M 1 k 432 M 2 k 864 M 2 k 864 M
1 day 100 86.4 M 200 172.8 M 500 432 M 1 k 864 M 2 k 1.728 G
2 days 50 86.4 M 100 172.8 M 200 345.6 M 500 864 M 1 k 1.728 G
3 days 20 51.84 M 50 129.6 M 100 259.2 M 200 518.4 M 500 1.296 G
When the time axis setting is 100 ms or greater (the settings surrounded by bold lines) and the trigger mode is Auto or Auto Level,
waveforms are displayed in roll mode.
Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate

YOKOGAWA DL850 ScopeCorder Specifications

General

Maximum Sampling Rate	100 MS/s
Power Supply	100 to 240 VAC, 50/60 Hz
Resolution	16-bit
Operating Temperature	5 to 40°C
Bandwidth	20 MHz
Input Types	Voltage, Temperature, Strain, Acceleration, Frequency, Logic, Current
Interfaces	Ethernet, USB, GP-IB
Trigger Modes	Edge, Window, Pattern
Number of Channels	Up to 128 (with multiple input modules)
Memory Capacity	Up to 2 G points (with /M4 option)
