(Continued from previous page)
Record Length
4 Gpoint 5 Gpoint 10 Gpoint 20 Gpoint 50 Gpoint
Time/div Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
6 h 10 k 2.16 G 20 k 4.32 G 20 k 4.32 G 50 k 10.8 G 200 k 43.2 G
7 h 10 k 2.52 G 10 k 2.52 G 20 k 5.04 G 50 k 12.6 G 100 k 25.2 G
8 h 10 k 2.88 G 10 k 2.88 G 20 k 5.76 G 50 k 14.4 G 100 k 28.8 G
9 h 10 k 3.24 G 10 k 3.24 G 20 k 6.48 G 50 k 16.2 G 100 k 32.4 G
10 h 10 k 3.6 G 10 k 3.6 G 20 k 7.2 G 50 k 18 G 100 k 36 G
12 h 5 k 2.16 G 10 k 4.32 G 20 k 8.64 G 20 k 8.64 G 100 k 43.2 G
1 day 2 k 1.728 G 5 k 4.32 G 10 k 8.64 G 20 k 17.28 G 50 k 43.2 G
2 days 2 k 3.456 G 2 k 3.456 G 5 k 8.64 G 10 k 17.28 G 20 k 34.56 G
3 days 1 k 2.592 G 1 k 2.592 G 2 k 5.184 G 5 k 12.96 G 10 k 25.9 G
When the time axis setting is 100 ms or greater (the settings surrounded by bold lines) and the trigger mode is Auto or Auto Level,
waveforms are displayed in roll mode.
Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate

YOKOGAWA DL850 ScopeCorder Specifications

General

Maximum Sampling Rate	100 MS/s
Power Supply	100 to 240 VAC, 50/60 Hz
Resolution	16-bit
Operating Temperature	5 to 40°C
Bandwidth	20 MHz
Input Types	Voltage, Temperature, Strain, Acceleration, Frequency, Logic, Current
Interfaces	Ethernet, USB, GP-IB
Trigger Modes	Edge, Window, Pattern
Number of Channels	Up to 128 (with multiple input modules)
Memory Capacity	Up to 2 G points (with /M4 option)
