YOKOGAWA DL850 ScopeCorder User Manual

App-8
IM DL850-03EN
When the High-Speed 100 MS/s, 12-Bit Isolation Module Is Not
Installed
When the Record Length Is 1 kpoint, 2.5 kpoint, 5 kpoint, 10 kpoint, or 25 kpoint
Record Length
1 kpoint 2.5 kpoint 5 kpoint 10 kpoint 25 kpoint
Time/div Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
Sample
Rate
(S/s)
Display
Record
Length
(Points)
1 μs 10 M 100 10 M 100 10 M 100 10 M 100 10 M 100
2 μs 10 M 200 10 M 200 10 M 200 10 M 200 10 M 200
5 μs 10 M 500 10 M 500 10 M 500 10 M 500 10 M 500
10 μs 10 M 1 k 10 M 1 k 10 M 1 k 10 M 1 k 10 M 1 k
20 μs 5 M 1 k 10 M 2 k 10 M 2 k 10 M 2 k 10 M 2 k
50 μs 2 M 1 k 5 M 2.5 k 10 M 5 k 10 M 5 k 10 M 5 k
100 μs 1 M 1 k 2 M 2 k 5 M 5 k 10 M 10 k 10 M 10 k
200 μs 500 k 1 k 1 M 2 k 2 M 4 k 5 M 10 k 10 M 20 k
500 μs 200 k 1 k 500 k 2.5 k 1 M 5 k 2 M 10 k 5 M 25 k
1 ms 100 k 1 k 200 k 2 k 500 k 5 k 1 M 10 k 2 M 20 k
2 ms 50 k 1 k 100 k 2 k 200 k 4 k 500 k 10 k 1 M 20 k
5 ms 20 k 1 k 50 k 2.5 k 100 k 5 k 200 k 10 k 500 k 25 k
10 ms 10 k 1 k 20 k 2 k 50 k 5 k 100 k 10 k 200 k 20 k
20 ms 5 k 1 k 10 k 2 k 20 k 4 k 50 k 10 k 100 k 20 k
50 ms 2 k 1 k 5 k 2.5 k 10 k 5 k 20 k 10 k 50 k 25 k
100 ms 1 k 1 k 2 k 2 k 5 k 5 k 10 k 10 k 20 k 20 k
200 ms 500 1 k 1 k 2 k 2 k 4 k 5 k 10 k 10 k 20 k
500 ms 200 1 k 500 2.5 k 1 k 5 k 2 k 10 k 5 k 25 k
1 s 100 1 k 200 2 k 500 5 k 1 k 10 k 2 k 20 k
2 s 50 1 k 100 2 k 200 4 k 500 10 k 1 k 20 k
3 s 20 600 50 1.5 k 100 3 k 200 6 k 500 15 k
4 s 20 800 50 2 k 100 4 k 200 8 k 500 20 k
5 s 20 1 k 50 2.5 k 100 5 k 200 10 k 500 25 k
6 s 10 600 20 1.2 k 50 3 k 100 6 k 200 12 k
8 s 10 800 20 1.6 k 50 4 k 100 8 k 200 16 k
10 s 10 1 k 20 2 k 50 5 k 100 10 k 200 20 k
20 s 5 1 k 10 2 k 20 4 k 50 10 k 100 20 k
30 s 5 1.5 k 10 3 k 20 6 k 50 15 k
1 min 5 3 k 10 6 k 20 12 k
2 min 5 6 k 20 24 k
3 min 5 9 k 10 18 k
4 min 10 24 k
5 min 5 15 k
6 min 5 18 k
7 min 5 21 k
When the time axis setting is 100 ms or greater (the settings surrounded by bold lines) and the trigger mode is Auto or Auto Level,
waveforms are displayed in roll mode.
Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate

YOKOGAWA DL850 ScopeCorder Specifications

General

Maximum Sampling Rate	100 MS/s
Power Supply	100 to 240 VAC, 50/60 Hz
Resolution	16-bit
Operating Temperature	5 to 40°C
Bandwidth	20 MHz
Input Types	Voltage, Temperature, Strain, Acceleration, Frequency, Logic, Current
Interfaces	Ethernet, USB, GP-IB
Trigger Modes	Edge, Window, Pattern
Number of Channels	Up to 128 (with multiple input modules)
Memory Capacity	Up to 2 G points (with /M4 option)
