App-14
IM DL850-03EN
Relationship between the Main Channel Sample Rate and the Sub
Channel Sample Rates of the 16-CH Temperature/Voltage Input
Module
Main Channel
Sample Rate
(S/s)
Number of Sub Channels:1 to 16
Maximum Sample Rate:10 k
100 M 100 k
50 M 100 k
20 M 100 k
10 M 100 k
5 M 100 k
2 M 100 k
1 M 50 k
500 k 20 k
200 k 10 k
100 k 5 k
50 k 2 k
20 k 1 k
10 k 500
5 k 200
2 k 100
1 k 50
500 20
200 10
100 5
50 2
20 1
10 -
5 -
If you set the sample rate (the main channel sample rate) of the DL850/DL850V to a rate that is higher than a module's maximum
sample rate, because the data is only updated at the module's maximum sample rate, all the data within the module's data update
interval will be the same.
Appendix 1 Relationship between the Time Axis Setting, Record Length, and Sample Rate
